Red Hat ENTERPRISE LINUX 5 - ADMINISTRATION Manual page 88

Appendix A. Example of Setting Up Apache HTTP Server
• Click Create a Resource.
• In the Resource Configuration dialog, select File System from the drop-down menu.
• Enter the Name for the resource (for example, httpd-content.
• Choose ext3 from the File System Type drop-down menu.
• Enter the mount point in the Mount Point field (for example, /var/www/html/).
• Enter the device special file name in the Device field (for example, /dev/sda3).
3. Add an IP address for the Apache HTTP Server service.
• Click Create a Resource.
• Choose IP Address from the drop-down menu.
• Enter the IP Address to be associated with the Apache HTTP Server service.
• Make sure that the Monitor Link checkbox is left checked.
• Click OK.
4. Click the Services property.
5. Create the Apache HTTP Server service.
• Click Create a Service. Type a Name for the service in the Add a Service dialog.
• In the Service Management dialog, select a Failover Domain from the drop-down menu or
leave it as None.
• Click the Add a Shared Resource to this service button. From the available list, choose each
resource that you created in the previous steps. Repeat this step until all resources have been
added.
• Click OK.
6. Choose File => Save to save your changes.
78
