- Page 1 TMS320-XDS100v3 DSP and ARM emulator and adapter USER’S MANUAL Revision E, January 2014 Designed by OLIMEX Ltd, 2013 All boards produced by Olimex LTD are ROHS compliant...
-
Page 2: Disclaimer
This document is intended only to assist the reader in the use of the product. OLIMEX Ltd. shall not be liable for any loss or damage arising from the use of any information in this document or any error or omission in such information or any incorrect use of the product. -
Page 3: Table Of Contents
1.1 Features ........................4 1.2 Target market and purpose of the board ..............5 1.3 Organization ....................... 5 CHAPTER 2 SETTING UP THE TMS320-XDS100v3 ........... 6 2. Introduction to the chapter ..................6 2.1 Electrostatic warning ....................6 2.3 Requirements ......................6 2.4 Cables, layouts, connection .................. -
Page 4: Chapter 1 Overview
Thank you for choosing the TMS320-XDS100v3 emulator from Olimex! This document provides a user’s guide for the Olimex TMS320-XDS100v3. As an overview, this chapter gives the scope of this document and lists the board’s features. The differences between the members of the TMS320- XDS100v3 family are mentioned. -
Page 5: Target Market And Purpose Of The Board
– Chapter 2 provides a guide for quickly setting up the board – Chapter 3 contains the general board diagram and layout – Chapter 4 mentions the main software tools used with TMS320-XDS100v3 – Chapter 5 is an explanation of the interfaces, the LEDs, the jumpers position –... -
Page 6: Chapter 2 Setting Up The Tms320-Xds100V3
2.1 Electrostatic warning TMS320-XDS100v3 is shipped in a protective anti-static package. The board must not be exposed to high electrostatic potentials. A grounding strap or similar protective device should be worn when handling the board. Avoid touching the component pins or any other metallic element. - Page 7 The Olimex XDS100v3 14pin JTAG has the exact layout of TI's 14pin JTAG. Both connector have 0.1'' step. The 20pin JTAG that might be found near the 14pin JTAG of TMS320-XDS100v3. It follows the same signal layout of the original TI XDS100v3 but it uses bigger connector with pin holes with 0.1'' step again (the original TI design suggests 0.05'').
-
Page 8: Powering The Board And Installation Procedure For Ccs 5
OLIMEX© 2013 TMS320-XDS100v3 user's manual *The entries NA means the standard signal was not routed (was not used for the JTAG connection). It is important to keep signal 6 (TDIS by default) to GND, else the board won't detect the target. -
Page 9: Powering The Board And Installation Procedure For Iar Ew For Arm 6
OLIMEX© 2013 TMS320-XDS100v3 user's manual C. Connect the XDS100 hardware 1. Make sure the Code Composer Studio 5.1.x and EmuPack with XDS100v3 support is installed FIRST before plugging in the XDS100 HW to the PC. 2. Connect USB cable from the PC to the XDS100 hardware. Connect the JTAG to the target board (be careful to plug it in correctly: pin 1 should go to pin 1. - Page 10 OLIMEX© 2013 TMS320-XDS100v3 user's manual “C:\Program Files (x86)\IAR Systems\Embedded Workbench for ARM 6\arm\drivers\ti-xds” C. Load a demo project and right-click over the project in the “Workspace” window. Select “Options” and click the “Debugger” group then choose “TI XDS100” from the drop-down menu.
-
Page 11: Chapter 3 Tms320-Xds100V3 Description
3. Introduction to the chapter Here you get acquainted with the main parts of the board. Note the names used on the board differ from the names used to describe them. For the actual names check the TMS320-XDS100v3 board itself. -
Page 12: Chapter 4 Interfaces And Hardware
Used for 14-pin JTAG connection. The JTAG_14 follows the JTAG layout of Texas Instruments. This interface might be used to communicate with Olimex TMS320-P28016 and Olimex TMX320- P28027. The interface might be used with any target that follows the 14-pin TI JTAG layout. -
Page 13: Leds
OLIMEX© 2013 TMS320-XDS100v3 user's manual 4.2 LEDs There are four LEDs on TMS320-XDS100v3. Two for indicating power input and power output and two for the current board-mode. 4.2.1 Power LEDs The PWR_LED shows whether the board is powered. The PWR_EN shows whether the board can power the target. -
Page 14: Chapter 5 Revision History And Support
OLIMEX© 2013 TMS320-XDS100v3 user's manual CHAPTER 5 REVISION HISTORY AND SUPPORT 5. Introduction to the chapter In this chapter you will find the current and the previous version of the document you are reading. Also the web-page for your device is listed. Be sure to check it after a purchase for the latest available updates and examples. -
Page 15: Useful Web Links And Purchase Codes
The web page you can visit for more info on your device is https://www.olimex.com/Products/DSP/Emulators/TMS320-XDS100-V3/. ORDER CODES: TMS320-XDS100v3 – completely assembled and tested JTAG emulator How to order? You can order to us directly via our internet shop or from any of our distributors. -
Page 16: Product Support
TMS320-XDS100v3 user's manual 5.3 Product support For product support, hardware information and error reports mail to: support@olimex.com. Note that we are primarily a hardware company and our software support is limited. Please consider reading the paragraph below about the warranty of Olimex products. -
