Using the DXP-HT Project Wizard

To edit the Display Name for an existing Preset Category

1. Select one from the list, and enter the new name in the Display Name text field.
2. Click Apply to apply the change.
3. Use the up/down arrow buttons to change the order in which the Preset Category buttons will
occur on the touch panel.
To delete a Preset Category from the list, select one and click the Delete button.

Channel Preset dialogs

The Channel Preset dialogs are the same for any TV type channel preset, including TV tuners,
Cable TV tuners, DSS tuner, PVR tuners and VCR tuners.
Channel Presets dialogs are only included for devices that have been specified as
being "tuner capable". This is an option that must be manually selected, in the Device
Data tab of the Device Configuration dialog.
You can setup a maximum of 100 channel presets for each tuner. Each tuner carries it own set of
channel presets.
FIG. 16 Channel Preset dialog
48
The Channel Presets table can be sorted by clicking on any of the three column header
cells (Order, Preset Name, Uses Logo and Channel). Clicking the header cells toggles
between sorting the column in ascending or descending order. Clicking on any of the
cells within the list selects the channel for editing. The arrow buttons to the right of the
channel list will move the selected channel up or down in the list order.
DXP-HT v1.3 - Programmer's Guide
