Choose Touch Panel Background dialog

To select a background for your custom touch panel theme, click on one of the background names
in the list on the left side of the screen.
FIG. 12 Choose Touch Panel Background dialog
Because of the amount of possible color combinations between backgrounds,
buttons and text, some combinations may be difficult to read on-screen. Be sure to
select color combinations with enough contrast (especially between text and
background color or image) that will be easy for the end-user to read. In some cases
you may need to make manual adjustments to ensure readability.

Choose Touch Panel Buttons dialog

To select a button style:
1. Expand the lists on the left side of the dialog and click on a button family style.
2. Click and drag a button color from the sample buttons across the top of the dialog.
3. Drag the sample button and drop it on the image that says Drag here to Update.
4. The button preview will update accordingly.

Choose Touch Panel Text Colors dialog

To select the touch panel text colors
1. Click and drag one of the colors from the color palette at the top of the dialog.
2. Drag and drop the color on the Text Off State or Text On State graphic, which says Drag here
to update.
DXP-HT v1.3 - Programmer's Guide
A small-scale preview image of the selected theme is displayed in this dialog.
Click on the Preview button to see a full size preview of the panel page.
Using the DXP-HT Project Wizard
