Introduction

Main Screen Command Buttons

If a project is not exported before deleting, you will not be able to bring the project
back into DXP-HT for modifications at a later date.

User Information dialog

This dialog (FIG. 2) appears the first time DXP-HT is launched, and prompts you to enter the user
information that will be used to identify the designer of the DXP-HT project (Created By, Company
Name, Phone and E-mail Address).
FIG. 2 User Information dialog
14
Create New Project: Click this command button to launch the Design XPress - Home
Theater Project Wizard. Use the Project Wizard to step through the process of designing
and configuring the system.
Open Project: Click to highlight a project in the Project Selection List, and click the
Open Project command button to open the selected Project. When a project is opened, the
first Wizard dialog (System Information) is displayed.
Copy Project: This option creates a copy of an existing Project, and allows you to give
the copy a new name (via the Copy Project dialog).
Delete Project: This option allows you to delete a Project from the Project Selection List,
and from your hard drive.
To remove a Project from the Project Selection List, without deleting the file from your
hard drive, export the file before deleting. Once exported, you can import the file back
into DXP-HT later.
To export a DXP-HT project, select File > Export Project.
Once this information is entered, this dialog will not automatically be shown again at
startup, but can always be accessed via the Edit menu.
The checkbox at the bottom of this dialog can be checked to prevent the dialog from
automatically appearing when the program is started, even if no data has been entered.
