Using the DXP-HT Project Wizard
For the AMX ALD-D48, the Address field value is fixed at a value of one (1) and is
read-only. This value corresponds to the Device ID of the keypad.
40
The identifier entered into the Preset Name text box is the name that will be displayed on
the touch panel. No duplicates allowed (8 characters maximum).
The Address field correspond to either the lighting controller address and the preset
number (as with AMX Radia), or the address of the keypad and the keypad button that
will be emulated (as with the LiteTouch controller).
For the AMX ALD-D48, the address is the 7-digit ID number of the ALD-D48 Device
Server.
For the AMX Radia the address is the AXlink address of the Radia MC.
The only valid keypad address characters are 0-9, A-F, and : (colon). For reference, here
are the formats for the various supported lighting systems:
Lighting Controller
• AMX ALD-D48
• AMX Radia
• Clipsal C-Bus
• DynaLite
• Lehigh DX2
• Lutron GRAFIK Eye
• Lutron Homeworks
Interactive
• Lutron RadioRA
• LiteTouch 5000LC
• Tridonic DALI
• Vantage Qlink
Click the Apply button after editing a preset to apply the changes.
The Button # refers to the button number or scene number the DXP-HT system is to
emulate when communicating to the lighting system.
For AMX Radia, the button # is the scene number to be recalled when this scene is
selected on the touch panel.
For Clipsal C-Bus and Dynalite systems (used primarily outside the U.S.), the button #
consists of the button number plus the fade rate, separated by a semi colon. For example:
(C-Bus): K:P:[A4:E1]:75:8 indicates network $E1, group address $A4, go to 75%
at 8-second fade rate.
Address Format
The Address value is fixed at a value of one
and is disabled. This value corresponds to the
Device ID of the keypad.
AXlink Device ID (1-255)The Address is the
AXlink device ID of the Radia MC.
Group Address:Network Address (using a hex
value and a local network address)
DynaLite area (positive integer)
Lehigh area (1 - 16)
Master (positive integer)
Processor:Link:Keypad (positive integers)
Keypad Address (positive integer)
Note: keypad address 12 is reserved as the
RS-232 RadioRA interface. This interface is a
virtual keypad, and does not contain any but-
tons.
Keypad Address (3 nibble hex value
Tridonic group address (0 -15)
Master:Keypad (positive integers)
DXP-HT v1.3 - Programmer's Guide
DXP-HT Example
1 (read-only)
96
A1:D4
18
1
17
1:4:9
12
A3E
0
1:5
