4. Select the required baud rate for the serial device from the Baud Rate drop-down list. (if
applicable).

Adding IP-Controlled Devices to the Project

To add a device to your system, click the Add button in the System Information dialog. This opens
the Device Configuration dialog - Device Data tab.
In the Source Configuration dialog (Source Data tab):
1. Select the type of equipment you are adding from the Source Type drop-down list.
2. Enter a name for the device in the Display Name field. This is the name for the device that will
appear on the touch panel.
3. If the device is a Compact Disc Player or Digital Video Disc player, specify the size of the disc
changer (if applicable; by default this field is set to 1).
4. Use the radio buttons to select IP as the Control Method associated with the new device.
The control method(s) available for selection depend on the device type specified.
5. Enter the IP Address of the ethernet-controlled device.

Adding a MAX-IMS or MMS Server to the System

To add a MAX-IMS or MAX-MMS server to your system, Click the Add button in the System
Information dialog to open the Device Configuration dialog - Device Data tab.
1. Select AMX MAX from the Source Type drop-down list.
2. Enter a name for the device in the Display Name field. This is the name for the device that will
appear on the touch panel.
3. Select the Control Logic, based on which type of MAX server you are adding (either IMS or
MMS).
4. In the IP Data field, enter the MAX server's IP Address.
5. Select an Output Zone number, which must be unique per each server used in a project. For
example, if a system has two MMS servers, each MMS could have an Output Zone 1.
The valid ranges are:
Each device IP Address must be unique, with only one exception: MAX servers can
use one IP with multiple output zones per display name entry. For example, a MAX-
IMS assigned to IP Address 1.1.1.1 - Zone 1 can exist in the same project as another
MAX-IMS assigned to IP Address 1.1.1.1 - Zone 2. But you cannot assign two MAX
servers with the same IP Address and Output Zone (you will receive an error
message).
DXP-HT v1.3 - Programmer's Guide
When you select a desired CD/DVD model from the Control Logic field, the changer size
is automatically filled and is read-only.
The control method(s) available for selection depend on the device type specified.
MAX-IMS = 1 to 8
MAX-MMS = 1 to 25
