Axxess AXDIS-LR92 Installation Instructions

Land Rover Range Rover Sport*
Land Rover Discovery**
(with M.O.S.T. 25 amplifier)
* 1st gen no time retention
** No time retention
† NAV screen will only show LR logo
INTERFACE FEATURES
• Provides accessory power
• Retains R.A.P. (retained accessory power)
• Designed for amplified models
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Micro-B USB updatable
INTERFACE COMPONENTS
• AXDIS-LR92 interface
• AXDIS-LR92 amplifier interface
• AXSWC interface
• AXDIS-LR92 harness
• AXSWC harness
• Female 3.5mm connector with stripped leads
AxxessInterfaces.com
Data Interface with SWC
(with M.O.S.T. 25 amplifier)
Data Interface with SWC
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
I N S TA L L AT I O N I N S T R U C T I O N S
2005-2009 †
TABLE OF CONTENTS
Connections to be made .......................................2
2004-2009 †
Installing the AXDIS-LR92 interface .....................3
Programming the AXSWC interface .....................3
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
CAUTION!
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AXDIS-LR92
All accessories, switches, climate
REV. 1/22/20 INSTAXDIS-LR92
