INTERFACE COMPONENTS
• AXDIS-LR82 interface
• AXDIS-LR82 amplifier interface
• AXSWC interface
• AXDIS-LR82 harness
• AXSWC harness
• M.O.S.T. jumper harness
• Female 3.5mm connector with stripped leads
AxxessInterfaces.com
Land Rover Range Rover Vogue
Data Interface w/ SWC
(w/ M.O.S.T. 25 amplifier)
2006-2012*
* Facelift models, with touchscreen. Excluding models with a Logic7 sound system
INTERFACE FEATURES
• Provides accessory power
• Designed for amplified models
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Micro-B USB updatable
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
AXDIS-LR82
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Connections to be made .......................................2
Installing the AXDIS-LR82 interface .....................3
Programming the AXSWC interface .....................3
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
REV. 12/17/20 INSTAXDIS-LR82
Advertisement
Related Manuals for Axxess AXDIS-LR82
Summary of Contents for Axxess AXDIS-LR82
- Page 1 TABLE OF CONTENTS Connections to be made ........2 Data Interface w/ SWC (w/ M.O.S.T. 25 amplifier) Installing the AXDIS-LR82 interface .....3 2006-2012* Programming the AXSWC interface .....3 * Facelift models, with touchscreen. Excluding models with a Logic7 sound system INTERFACE FEATURES •...
- Page 2 CONNECTIONS TO BE MADE From the aftermarket radio to the AXDIS-LR82 harness: • Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White wire of the connector. Then connect the remaining steering wheel control wire, normally • Connect the Black wire to the ground wire.
- Page 3 Manufacturer corresponds to which flash. • Connect the AXDIS-LR82 harness to the wiring harness in the vehicle. * • Connect the AXSWC harness to the AXSWC interface, and then to the AXDIS-LR82 interface. L.E.D. feedback legend • Connect the M.O.S.T. jumper harness to the factory fiber optic cable from the display screen.
- Page 4 Have the vehicle apart and ready to perform troubleshooting steps before contacting Metra/Axxess Tech Support. ® NOWLEDGE IS OWER Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry.
