- Page 1 MMR.30018 Replacement Grille MMR.30019 (1) Contents: Part Name Size(mm) Part Name Size(mm) I×8 Replacement Grille Flange Hex Lock Nuts H×8 Button Head Socket Cap Bolts Screws M4*10...
- Page 2 About 1 hour, 2-3 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (MMR.30018 &MMR.30019), please scan the QR code.
- Page 3 (4) Installation instruction: Step 1: Assemble the Part “A” & the Part “B1” ,”B2” with the Part “H” & the Part “I”.
- Page 5 Install the Part “K“ into the grille, as the picture shown. Step 2: Remove the original grille, Ready to install our product.
- Page 6 Negative wiring The black wire is the negative pole, you can mount it directly on the iron frame of the vehicle body.
- Page 7 Positive wiring （ 1 ） Place the positive wire according to the position shown in the figure below. Find the position of the ACC system (F50) according to the prompt on the back of the cover and connect it to the positive pole. Find ACC system （Daytime running lights）...
- Page 8 Step 3: Install the Part”J” into your vehicle. Step 4: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product!
- Page 9 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
