- Page 1 Tailgate Table MMR.31830 (1)Contents: (2)Tools required: A.10mm Wrench； B.4mm HEX Socket Wrench； （or Allen Wrench） C.Drill； D. 12mm Drill Bit；...
-
Page 2: Installation Time
(3)Installation time: About 1 hour, 1-2 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) (4)Installation instruction: Step 1: Remove the cover plate. Step 2: Drill 4 12mm bolt holes.The figure shows where to drill it. - Page 3 Step 3: After “Step 2”,then as shown below. Step 4: Assemble the PART”A” & PART”B” with PART”G” & PART”H”,and then install it on the tailgate with the PART”E”,PART”K” & PART”J”.
- Page 5 Step 5: Assemble the PART “A” & “B” using PART “F”, “D” and ”I”.
- Page 6 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
