- Page 1 MMR.20143 Inter Cargo Rack (1) Contents: Part Name Size(mm) Part Name Size(mm) Interior Cargo Back Assembly Split Lock Washer Button Head Socket Cap Bolts Screws M10*20 Flat Washer Flange Hex Lock Nuts...
- Page 3 About 1 hour, 2-3 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (MMR.20143), please scan the QR code.
- Page 4 (4) Installation instruction: Step 1: Put down the rear seats, empty the rear row and prepare to install the luggage rack. Step 2: Install the Left (A1) & Right (A2) Brackets into your vehicle with the factory bolts. As the picture shown.
- Page 5 Step 3: Assemble the Left (A1) & Right (A2) Brackets & the Cargo Rack (B) with the Button Head Socket Cap Bolts Screws (M8*20), Split Lock Washer (D8), Flat Washer (M8), Flange Hex Lock Nuts (M8). As the picture shown. Step 4: The instructions for use of this Net (Part C) and the EVA Foam Strips are shown in the picture below.
- Page 6 Step 5: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product! Attention: 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product.
