- Page 1 MMR.10023 Tailgate Table (1) Contents: Part Name Size(mm) Part Name Size(mm) Tailgate Table J×4 Rivet Nuts M6*15 H×2 Button Head Socket Cap Bolts Screws M6*16 K×2 Rubber Stopper M6*11 I×2 Button Head Socket Cap Bolts Screws M6*25 M×1 Locating Paper...
-
Page 2: Installation Time
(2) Tools required: a. 4mm Hex Bit Socket; b. Drive Socket Ratchet Wrench; c. Drill with 9.2-9.5mm Drill Bit; d. Pneumatic Riveting Nut Gun with 6mm Nut Chuck; (3) Installation time: About 1 hour, 2 people needed. Installation time may differ according to your mechanical skill level. - Page 3 Step 2: With the help of the locating points, drill four mounting holes on the tailgate. Step 3: Use the pneumatic riveting nut gun with 6mm nut chuck to install the four riveting nuts.
- Page 4 Step 4: Install the tailgate table with supplied bolts.
- Page 5 Step 5: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product! Attention: 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product.
