- Page 1 EXCEED RUNNING BOARD FOR TOYOTA HIGHLANDER 08-13 INSTALLATION INSTRUCTIONS EXCEED RUNNING BOARD FOR TOYOTA HIGHLANDER 08-13 PART # EX-TYHG Page 1 of 5 7/31/14 (DP)
-
Page 2: Parts List
EXCEED RUNNING BOARD FOR TOYOTA HIGHLANDER 08-13 PARTS LIST: Driver/Left Running Board 10-1.5mm x 50mm Hex Bolts Passenger/Right Running Board 10mm x 27mm OD x 3mm Flat Washers Driver/Left Front Mounting Bracket 10mm Lock Washers Passenger/Right Front Mounting Bracket 10mm Hex Nuts Driver/Left Rear Mounting Bracket 6mm T-Bolts Passenger/Right Rear Mounting... - Page 3 EXCEED RUNNING BOARD FOR TOYOTA HIGHLANDER 08-13 5. Carefully unwrap the Running Boards. From either open end, slide (3) T-Bolts into each channel in the bottom of the Running Board, (Figure 10). Slide the T-Bolts forward or back to line up with the slots in the (2) previously installed Mounting Brackets. Hold the Running Board up to the vehicle at a slight angle and gently push it into position against the rocker panel.
- Page 4 EXCEED RUNNING BOARD FOR TOYOTA HIGHLANDER 08-13 Passenger Side Installation Pictured (2) 10mm Flat Washers (2) 10mm Lock Washers Offset Rear (2) 10mm Hex Nuts Front Front (Fig 3) Bottom of Passenger side front Bracket Fig 4 pictured. IMPORTANT: Note rear offset mounting tab 10mm x 50mm Hex Bolt Front Support Plate...
- Page 5 EXCEED RUNNING BOARD FOR TOYOTA HIGHLANDER 08-13 Passenger Side Installation Pictured (2) 10mm Flat Washers Rear (2) 10mm Lock Washers (2) 10mm Hex Nuts (Fig 9) Passenger rear Bracket installation Fig 10 Front Tilt the Running Board up and push back into position against rocker panel.
