T-Rex 20460 Manual

20460
02-05 DODGE
RAM TRUCKS
4 PC. BILLET
BILLET INSERT
Tools Required:
1/16" Punch
Small Hammer
Phillips Screwdriver
Read and understand instructions before attempting installation
Step1
Remove the factory grille from vehicle and place it face down on a workbench. The factory chrome grille has
two rectangle plastic inserts held in by 11 plastic rivets each. Knock the center pin out of each rivet with a
1/16" center punch and remove the rivets.
discard the factory rivets. Remove the two inserts by hand.
Step2
Match the billet inserts to the opening it will be mounted in. Lay the billet inserts down and match them to
the original plastic mounts on the chrome shell.
Step3
Place each billet in the shell. Now thread a #8 screw and clip at each outer end bracket but do not tighten
(there are eight total). The remaining brackets will be fastened using the factory plastic rivets. After the rivets
have been installed, tighten the screws at the outer brackets.
Step4
Re-install the grille on the vehicle. Your installation is now complete.
Thank you for purchasing a T-Rex billet grille.
02-05 Dodge Ram Trucks
(All Models)
Some of the plastic rivets will be re-used later.
Hardware / Parts List (bolt-on):
4 - Billet Inserts (11 bars each)
8 - #8 x ¾ Phillip Screws
8 - #8 Flat Nuts
4/26/04 T-Rex Truck Products Inc.
