T-Rex 20564 Manual

20564
08-10 FORD
S U P E R DUTY
Tools Required:
Slotted Screwdrivers
Masking Tape
Read and understand instructions before attempting installation
Step 1
Apply masking tape to the fender (around the factory side vent). Each vent consists of two pieces and is secured
by eight metal pressure clips. The area with the F-250 or F-350 script is a separate piece from the lower section.
The piece with script must be removed first (1). Use a plastic interior removal tool or slotted screw driver to pry the
top assembly from the fender. Then remove the lower assembly.
1
4
2008-10 FORD SUPER DUTY
SIDE VENT INSERT – 2 PC
Hardware / Parts Included:
2 Billet Inserts (Driver / Passenger)
2
Step 2
Use a small slotted screwdriver to remove the pair of round clips securing the
inner mesh to the frame (2). Remove the mesh (3). Center the billet into the
frame; use the factory clips to secure the billet (4).
Step 3
Re-install the assemblies onto the vehicle. Install the lower section first; then
Thank you for purchasing a T-Rex Billet Grille.
the upper.
20564
08-10 FORD
S U P E R DUTY
3
3/22/07
