- Page 1 BLACK MODULAR GRILL GUARD FOR NISSAN FRONTIER 05-20/ PATHFINDER 05-07 INSTALLATION INSTRUCTIONS BLACK MODULAR GRILL GUARD FOR NISSAN FRONTIER 05-20/ PATHFINDER 05-07 PART # 17A110200MA Page 1 of 5...
-
Page 2: Parts List
BLACK MODULAR GRILL GUARD FOR NISSAN FRONTIER 05-18/ PATHFINDER 05-07 PARTS LIST: 1 Grille Guard 2 Hex bolt M8_25 1 Driver/Left Mounting Bracket 4 Flat washer D10(10x20x2mm) 1 Passenger/Right Mounting Bracket 2 M10 Hex nut M10 1 Driver/Left Top Bracket (for 05-08 vehicles) 6 Hex nut M12 1 Passenger/Right Top Bracket (for 05-08 vehicles) 2 Button Head Bolt M10_25... - Page 3 BLACK MODULAR GRILL GUARD FOR NISSAN FRONTIER 05-18/ PATHFINDER 05-07 12mm Lock Washers, (12) 12mm Flat Washers and (6) 12mm Hex Nuts, (Figure 7). Do not tighten at this time. 8. Push the Grille Guard back into position and line up the holes in the Top Brackets with the holes in the Grille Guard uprights.
- Page 4 BLACK MODULAR GRILL GUARD FOR NISSAN FRONTIER 05-18/ PATHFINDER 05-07 Driver Side Installation Pictured 05-08 driver side Top Bracket Fig 5 09 driver side Top Bracket Remove plastic factory clips. Insert 8mm Nut plate into opening Fig 4 in grille and line up with this hole 05-08 driver side Top Bracket installation pictured 8mm x 25mm Hex Bolts...
- Page 5 BLACK MODULAR GRILL GUARD FOR NISSAN FRONTIER 05-18/ PATHFINDER 05-07 Button Head Bolt M8_20 Nut M8 Flat washer D8 (8x16x1.6mm) Page 5 of 5...
