Electronic Control Units (ECUs)

Identification
Frame mount ECUs are environmentally packaged versions
of the related Gen 4 ™ & Gen 5 ™ ABS cab-mounted units
(Standard, Basic). The circuitry and software is the same.
Gen 5 ™ ABS units incorporate power line carrier (PLC)
hardware. ECUs are available in 4 and 6-channel versions
with either J1922 or J1939 data links. There is also a 24-
volt version. Further service information is available on
www.bendix.com.
Bendix Part Number
Bendix Part Number
Serial Number
Date Code
Date Code
Frame Mount
Cab Mount
Serial Number
FIGURE 6 - Electronic Control Unit Identification Tags
