Blink Codes
1st.
2nd.
6
1
6
2
6
3
6
4
6
5
6
6
6
7
6
8
7
1
7
2
7
3
7
4
7
5
7
6
7
7
7
8
8
1
8
2
8
3
8
4
8
5
8
6
8
7
8
8
8
10
8
10
9
1
9
2
9
3
9
4
9
5
9
6
9
7
9
8
22
MID 136
SID/FMI
005/000
Sensor air gap too large.
005/008
Air gap too large or sensor shorted.
005/010
Speed Sensor signal is noisy.
005/008
Wheel locked for too long during an ABS cycle.
005/008
High deceleration rate at wheel site or sensor shorted.
005/012
Sensor shorted low or high or sensor open.
005/012
Internal error at the sensor port of the ECU.
005/002
Sensor in the wrong location for the system configuration.
006/000
Sensor air gap too large.
006/008
Air gap too large or sensor shorted.
006/010
Speed Sensor signal is noisy.
006/008
Wheel locked too long during an ABS cycle.
006/008
High deceleration rate at wheel site or sensor shorted.
006/012
Sensor shorted low or high or sensor open.
006/012
Internal error at the sensor port of the ECU.
006/002
Sensor in the wrong location for the system configuration.
007/003
Short circuit from the release solenoid to voltage.
007/004
Short circuit from the release solenoid to ground.
007/005
Open circuit at the release solenoid.
007/005
Open circuit on the common line to the valve.
007/003
Short circuit from the hold solenoid to voltage.
007/004
Short circuit from the hold solenoid to ground.
007/005
Open circuit at the hold solenoid.
007/002
System configuration is incorrect.
151/014
Inter-axle differential control circuit shorted high.
151/014
Inter-axle differential control circuit shorted low or open.
008/003
Short circuit from the release solenoid to voltage.
008/004
Short circuit from the release solenoid to ground.
008/005
Open circuit at the release solenoid.
008/005
Open circuit on the common line to the valve.
008/003
Short circuit from the hold solenoid to voltage.
008/004
Short circuit from the hold solenoid to ground.
008/005
Open circuit at the hold solenoid.
008/002
System configuration is incorrect.
Description
Location
Left Rear Sensor.
Left Rear Sensor.
(continued).
Right Rear Sensor.
Left Steer Axle PMV.
IAD Circuit.
Right Steer Axle PMV.
