BENDIX GEN 4 GEN 5 ABS Manual page 44

X1 Grey
Pin Signal
X1-1 IGN
1
X1-2 IGN
2
X1-3 ATCL
X1-4 1587
+
X1-5 RET
X1-6 ENG
–
X1-7 ENG
+
X1-8 SHLD/TIL
X1-9 1587
–
X1-10 WL
X1-11 GND
2
X1-12 GND
1
X2 Black
Pin Signal
X2-1 BLS
X2-2 HLD
LS
X2-3 REL
RS
X2-4 HLD
RS
X2-5 SS
RS
X2-6 SS
BS
X2-7 SS
LS
X2-8 SS
LS
X2-9 CMN
RS
X2-10 REL
LS
X2-11 CMN
LS
X2-12 ORS
FIGURE 45 - Frame Mount ECU – Pin Identification Chart
44
Description
Ignition-1
Ignition-2
ATC Light/ATC Switch
J1587+
Retarder Control
J1922/1939 Engine Control Link-
J1922/1939 Engine Control link+
™ ™
Gen 4 ABS J1939 Shield/Gen 5 ABS TIL
J1587-
ABS WL/Diagnostic Switch
Ground
Ground
Description
Brake Light Switch
Hold Sol, Left Steer
Release Sol, Right Steer
Hold Sol, Right Steer
Speed Sensor, Right Steer-
Speed Sensor, Right Steer+
Speed Sensor, Left Steer-
Speed Sensor, Left Steer+
Common, Right Steer Valve
Release, Left Steer Valve
Common, Left Steer Valve
Off Road Switch
X3 Green
Pin Signal Description
X3-1 SS Speed Sensor, Left Rear-
LR
X3-2 SS Speed Sensor, Left Rear+
LR
X3-3 SS Speed Sensor, Right Rear-
RR
X3-4 SS Speed Sensor, Right Rear+
RR
X3-5 ATCV Traction Control Valve-
-
X3-6 ATCV Traction Control Valve+
+
X3-7 REL Release Sol, Right Rear
RR
X3-8 CMN Common, Right Rear
RR
X3-9 HLD Hold Sol, Right Rear
RR
X3-10 REL Release Sol, Left Rear
LR
X3-11 CMN Common, Left Rear
LR
X3-12 HLD Hold Sol, Left Rear
LR
X4 Brown
Pin Signal Description
X4-1 DLC Diff Lock Control-
-
X4-2 DLC Diff Lock Control+
+
X4-3 SS Speed Sensor Left Rear Rear-
LRR
X4-4 SS Speed Sensor Left Rear Rear+
LRR
X4-5 SS Speed Sensor Right Rear Rear-
RRR
X4-6 SS Speed Sensor Right Rear Rear+
RRR
X4-7 REL Release Sol, Right Rear Rear
RRR
X4-8 CMN Common, Right Rear Rear
C+
X4-9 HLD Hold Sol, Right Rear Rear
RRR
X4-10 REL Release Sol, Left Rear Rear
LRR
X4-11 CMN Common, Left Rear Rear
LRR
X4-12 HLD Hold Sol, Left Rear Rear
LRR
