HRS DF62W WP Manual

1. Scope
This document specifies the steps from crimping the DF62W-series crimped terminals to
cables (AWG20 to AWG30) to inserting the terminals to crimping sockets,and inserting the
terminal into the crimp case, and the procedure for mounting the panel of the DF62WP
series.
2. Connectors
 Crimping cases
DF62W # –  EP – 2.2 C
    

5
Name: DF62W or DF62WZ

Wire seal
#=None or A to E

No. of poles: 2 to 9

Connector types
S : Socket
EP: In-line plug

Contact pitch: 2.2 mm
❻
Shape of connection/terminal
C : Crimping case

 Crimping cases (Panel waterproof type)
DF62WP – ＊/＊/＊/＊ EP – 2.2 C



Name: DF62WP


No. of poles: 2 to 9
" /" Indicates that the connector is a
composite connector with a number of
poles separated by it.

Connector types
EP: In-line plug

Contact pitch: 2.2 mm

Shape of connection/terminal

C : Crimping case


 Water proof pin
DF62W – WP


Application
WP: Waterproof pin
COUNT DESCRIPTION OF REVISIONS
5
3
TITLE
DF62W Series Cable Assembly Procedure
DF62WP series panel installation procedure
TECHICAL SPECIFICATION
FORM HC0011-9-1
