  • Page 1 Owner’s Manual Models: Arros 9, Arros 15, Arros 22 NSF Standard 55 Class B Validated Models: Arros 9-V, Arros 15-V, Arros 22-V Arros 9-V, Arros 15-V, Arros 22-V Tested and Certified by NSF International against CSA B483.1 and NSF/ANSI 55 for Disinfection Performance, Class B 425 Clair Rd.
  • Page 2 • VIQUA replacement lamps undergo rigorous performance testing and strict quality control processes to ensure that the safety and performance certifications of the original equipment are not compromised. So, you can see that it's simply not worth the risk! Insist on genuine VIQUA replacement lamps.

  • Page 3: Safety Information

    Safety Information Section 1 Safety Information These are the original instructions. Please read this entire manual before operating this equipment. Pay attention to all danger, warning, and caution statements in this manual. Failure to do so could result in serious personal injury or damage to the equipment.

  • Page 4: Safety Precautions

    Safety Information 1.2 Safety Precautions: D A N G E R Failure to follow these instructions will result in serious injury or death. • Electric Shock: To avoid possible electric shock, special care should be taken since water is present near the electrical equipment. Unless a situation is encountered that is explicitly addressed by the provided maintenance and troubleshooting sections, DO NOT attempt repairs yourself, refer to an authorized service facility.

  • Page 5: Water Chemistry

    • The Arros 9, Arros 15 and Arros 22 UV systems have been validated through microbial testing. Through this testing, performance data has been generated for UV dose delivery to inactivate Cryptosporidium, Giardia, Escherichia coli (E. coli) and Fecal Coliform.

  • Page 6: General Information

    Arros 22, Arros 22-V Arros Controller 100-240VAC/50/60Hz VA-CTRL All Models 260244-R Arros 9, Arros 15, Arros 22 260245-R Arros 9/2, Arros 15/2, Arros 22/2 IEC replacement Power Cords for Arros Controller (Sold separately) 260246-R Arros 9/2B, Arros 15/2B, Arros 22/2B...
  • Page 7 Installation of UV System Section 3 Installation of UV System C A U T I O N Electronic controller must be connected to a Ground Fault Protected Circuit (GFCI) receptacle. Ensure green ground wire ring terminal is securely fastened to ground stud on UV chamber. 3.1 Installing UV System The UV system is designed to be mounted either horizontally or vertically at the point-of-use or point-of-entry depending on the specific flow rate of the unit.
  • Page 8 Installation of UV System Procedure: Figure 3 shows the installation of a typical UV system and the related components that may be used for the installation. The use of a by-pass assembly is recommended in case the system requires “off-line” maintenance. In this case, note the system requires a supplementary disinfection for the distribution system if any water is used during by-pass condition.
  • Page 9 Installation of UV System Min. clearance equal Unit overall length to unit overall length Inlet Port Inlet Port Figure 4 UV Installation - Vertical and Horizontal 3. Mount the system to the wall using the supplied bracket. Various connection methods can be used to connect the water source to the system, however union type connectors are recommended.
  • Page 10 Installation of UV System 4. Reversing the inlet and outlet ports. The factory configuration of the UV system is with the inlet port on the left side of the unit. If required due to plumbing installations then this can be reversed as follows: •...

  • Page 11: Cleaning Procedure

    Installation of UV System 6. When all plumbing connections are complete, slowly turn on the water supply and check for leaks. The most likely cause of leaks is from an O-ring seal. In case of a leak, shut water off, drain chamber, remove the lamp unit or drain plug, wipe the O-rings and threads.

  • Page 12: Maintenance

    Maintenance 10 10 • Shut off the water supply. • Press the pressure button to • With all faucets closed, • Reinstall the cartridge(s) into purge air and to complete the remove filter housing(s) using filter housing(s) and connect • Press the pressure button to cleaning procedure.
  • Page 13 Maintenance Procedure: 10 mins • Disconnect main power • Shut off the water line to UV • To remove lamp unit rotate • To remove lamp connector from source and allow the unit to chamber and release system counter clockwise until the lamp the lamp unit pull lamp cool for 10 minutes.
  • Page 14 Operations Section 5 Operations WA R N I N G The advanced warning system has been installed to provide the optimum protection against microbiological contamination in water. DO NOT disregard the warning signals. The best way to ensure optimum UV performance is to have the water microbiologically tested by a recognized testing agency on a regular basis.

  • Page 15: Home Screen

    Operations c. Screen Orientation Setup: When mounting the UV system in a horizontal installation the Display Screen can be configured to the most preferred orientation. Click on the arrows to change the LCD screen orientation. Once desired orientation is shown press done. Figure 9 Startup Sequence d.
  • Page 16 Operations 4. A Major Lamp Alarm will be initiated once the lamp life reaches 0 days. Note: Use of a non-VIQUA lamp unit will result in an ongoing fault mode (major lamp alarm) and will impair accurate lamp-life tracking. Lamp On...

  • Page 17: Menu Screen

    Operations 5.3 Menu Screen 1. From the Home Screen, press the top left icon to access the main menu screen. 2. The Menu Screen provides access to four main user screens: Figure 12 Menu Screen a. A spare parts menu screen for finding replacement part numbers. Figure 13 Spare Parts Menu b.
  • Page 18 Operations c. Information menu which provides system information such as firmware version, Model number and serial number. Figure 15 Information Menu d. Contact dealer information menu provides information on finding a dealer in your area. Figure 16 Contact Dealer Information Menu 5.4 Lamp Head Status Lights The white top cap (Halo) of the lamp assembly will illuminate when the lamp is operating.

  • Page 19: Firmware Updates

    Troubleshooting 5.5 Firmware Updates 1. When firmware updates are developed to enhance the performance or add features to the current controller this new firmware can be uploaded via a smart phone and associated downloadable application program. 2. For details on this feature go to www.trojantechnologies.com for details of when upgrades are available and instructions on how to upload the new firmware.
  • Page 20 Manufacturer’s Dose Flow Chart Section 7 Manufacturer’s Dose Flow Chart UV Dose Curves at 95% UVT @ EOL Arros 22 Arros 15 Arros 9 15 16 20 6 6 0 UV Dose (FLUENCE) (mJ/cm ) 1966 US Public Manufacturer’s NSF/EPA,...

  • Page 21: Specifications

    Specifications Section 8 Specifications ARROS 9 ARROS 15 ARROS 22 Model ARROS 9-V ARROS 15-V ARROS 22-V *NSF class B certified 6.4 gpm (24.2 lpm) (1.45 m /hr) 9.4 gpm (35.58 lpm) (2.13 m /hr) 12.9 gpm (48.8 lpm) (2.93 m...

  • Page 22: Section 9 Manufacturer's Warranty

    VIQUA warrants the electrical (controller) and hardware components to be free from defects in material and workmanship for a period of five (5) years from the date of purchase. During this time, VIQUA will repair or replace, at its option, any defective parts covered by the warranty.
  • Page 23 425 Clair Rd. W, Guelph, Ontario, Canada N1L 1R1 t. (+1) 519.763.1032 • tf. (+1) 800.265.7246 (US and Canada only) t. (+31) 73 747 0144 (Europe only) • f. (+1) 519.763.5069 e-mail: info@viqua.com www.viqua.com...
