Introduction
Display screen
The service tool screen is a backlit LCD capable of displaying four rows of text
containing up to twenty characters.
Keypad
Esc
CON0018
The service tool is operated via the 6-button keypad.
The table below details the keypad buttons and their functionality.
Key
Function
Select a menu option, Continue or Yes.
Exit a menu or No.
Scroll up within a menu or text.
Scroll down within a menu or text.
Scroll left and right.
Provide context sensitive help (where available).
