VDO CONTISYS OBD Instruction Manual page 25

FastCheck
CON0017
If using the EOBD (J1962) pin-switchable cable (A2C59512073), ensure the settings
on the switch box correspond to the settings listed for the vehicle and system being
tested.
WARNING: Incorrect settings on the switch box may cause irreparable damage to
the vehicle's electrical system.
Ensure the vehicle's ignition is OFF.
Connect the service tool to the required vehicle connector, refer to
connector locations', page
Power for the service tool is provided by the vehicle connector. Once connected, the
service tool will perform an internal self test and then the screen will display the version
of the current software before displaying the main menu.
Use the and keys to select the 'FastCheck ABS' application and press
confirm the selection. To return to the previous menu, press the
Turn the vehicle's ignition ON.
Use the and keys to select the vehicle manufacturer and press
the selection.
Dependent upon the vehicle and application being run, you may be asked to choose
the particular system fitted to the vehicle. Select the correct system using the
keys and press
G
F
E
H
D
I
C
J
B
K
A
L
57, for further information.
MAIN MENU
1. EOBD
2. FastCheck ABS
3. FastCheck Airbag
4. FastCheck Climate
5. FastCheck EPB
6. FastCheck SAS
7. FastCheck Service
8. User Menu
to confirm.
7
6
5 8
4
9
3
10
2 11
1
12
'Diagnostic
to
key.
to confirm
and
21
