TP-Link TL-SG1008 User Manual
8-port/16-port/24-port/48-port gigabit ethernet switch
Hide thumbs
Also See for TL-SG1008:
- Installation manual (32 pages) ,
- User manual (6 pages) ,
- Installation manual (24 pages)
Subscribe to Our Youtube Channel
Related Manuals for TP-Link TL-SG1008
Summary of Contents for TP-Link TL-SG1008
- Page 1 TP-LINK TECHNOLOGIES CO.,LTD. E-mail Support@tp-link.com Website http:// www.tp-link.com.cn ADD FI.3,Bldg.R1-B.High-Tech Industrial Park,Shenzhen Road.Shenzhen.China...
- Page 2 User’s Guide TL-SG1008 8-port Gigabit Ethernet Switch TL-SG1016 16-port Gigabit Ethernet Switch TL-SG1024 24-port Gigabit Ethernet Switch TL-SG1048 48-port Gigabit Ethernet Switch...
-
Page 3: Ce Mark Warning
No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2007 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com FCC STA TEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Safety Notices
radio interference, in which case the user may be required to take adequate measures. SAFETY NOTICES Cautions Do not use this product near water, for example, in a wet basement or near a swimming pool. Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning. -
Page 5: Table Of Contents
CONTENTS Package Contents ..............1 Chapter 1 Introduction of the Product......2 Overview of the Product...............2 Features..................2 Chapter 2 Installation............4 Mounting the Switch on a Desk............4 Mounting the Switch in a Rack............4 Power On ..................5 Chapter 3 Identifying External Components....7 Rear Panel ..................7 LED Indicators ................7 Appendix A: Specifications ........... -
Page 6: Package Contents
TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048 Gigabit Ethernet Switch User Guide Package Contents The following contents should be found in your box: One Gigabit Ethernet Switch One power cord This User's Guide Rubber footpads for Desk-mount Rack-mount kit for installing the switch in a 19-inch rack... -
Page 7: Chapter 1 Introduction Of The Product
TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048 Gigabit Ethernet Switch User Guide Chapter 1 Introduction of the Product This chapter describes the features of the Gigabit Ethernet Switch. Overview of the Product The Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to boost your old network to 1000Mbps. - Page 8 Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput 4K entry MAC address table of the TL-SG1008 and 8K entry MAC address table of the TL-SG1016, TL-SG1024 and TL-SG1048 with auto-learning and auto-aging...
-
Page 9: Chapter 2 Installation
Switch bottom, then lay the Switch on the desktop, where can be able to withstand 5kg of weight. TL-SG1008, TL-SG1016, TL-SG1024 and TL-SG1048 are different in the number of LED indicators and RJ45 ports. All figures are of TL-SG1008 in this user's guide. Note Make sure there is a grounded AC outlet within 1.5 meters, and working... -
Page 10: Power On
All of the 10/100Mbps Link/Act and 1000Mbps Link/Act LED indicators of the TL-SG1008 will flash momentarily at first, flash sequence later and flash momentarily lastly, which represent a resetting of the system. All of the 10/100Mbps Link/Act and 1000Mbps Link/Act LED indicators of the... - Page 11 TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048 Gigabit Ethernet Switch User Guide TL-SG1016/TL-SG1024 /TL-SG1048 will flash momentarily for one second, which represent a resetting of the system. The Power indicator will light up all the time. If the LED indicators don’t respond as described above, please check the...
-
Page 12: Chapter 3 Identifying External Components
Figure 3-1 TL-SG1008 Switch Front Panel sketch Rear Panel The rear panel of the TL-SG1008 only features a power receptacle, which is an AC power receptacle. Connect the female of the power cord head here, and the male head to the AC power outlet. - Page 13 TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048 Gigabit Ethernet Switch User Guide Figure 3-3 TL-SG1008 Switch LEDs sketch Power LED: This indicator will light solid red when the Switch powers up. If the LED is not lit, please check the power supply and connection. 1000Mbps Link/Act LED: This indicator will light solid green when the corresponding port is connected to a 1000Mbps device and will flash green when data is being transmitted or received on the working connection.
-
Page 14: Appendix A: Specifications
TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048 Gigabit Ethernet Switch User Guide Appendix A: Specifications General IEEE802.3 10Base-T Standards IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T Topology Star Protocol CSMA/CD Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex) Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Data Transfer Rate Duplex) Gigabit Ethernet: 2000Mbps (Full Duplex) 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ù... -
Page 15: Appendix B: Troubleshooting
TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048 Gigabit Ethernet Switch User Guide Appendix B: Troubleshooting The Power LED is not lit Make sure the AC power cord connected the Switch with power source properly. Make sure the power source is ON. The Link/Act LED is not lit when a device is connected to the...
