Installation & User Instructions:
Model: Arizona/Broadway/Corsano/Compton/Compton1000/Corbiere/Empire
/Newark/Newark1000/Qube/Tribeca
Once installed, the installer should take the appropriate steps
To ensure that the user understands how the appliance operates and
Should make the customer aware of the fires/suite basic servicing requirements.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Compton and is the answer not in the manual?

Questions and answers

Related Manuals for Evonicfires Compton

Summary of Contents for Evonicfires Compton

  • Page 1 Installation & User Instructions: Model: Arizona/Broadway/Corsano/Compton/Compton1000/Corbiere/Empire /Newark/Newark1000/Qube/Tribeca Once installed, the installer should take the appropriate steps To ensure that the user understands how the appliance operates and Should make the customer aware of the fires/suite basic servicing requirements.
  • Page 2 IMPORTANT INFORMATION All Evonic Fires Ltd products meet the requirements of the EC Directives 2004/108/EC and 2006/95/EC. These directives have been met by compliance with the following standards: BS EN 60335-1:2002 BS EN 60335-2-30:2003 BS EN 6100-6-3:2001 Please read these instructions before installation or use and keep this booklet handy for future reference. Safety: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by...
  • Page 3 Replacement plug: (Please note that it may invalidate your warranty is the moulded plug is removed) This appliance must only be connected to a 230/240 Volts AC 50Hz supply. Before connecting the fire, check that the supply voltage is the same as stated on the fire. This appliance must only be used on a AC supply, fuse rating 13Amp. The wires in the mains lead are coloured in accordance with a standard UK supply, these being: GREEN/YELLOW –...
  • Page 4 OPERATING INSTRUCTIONS The appliance can be operated manually using the rocker switch to the right of the heater outlet, or by remote control. (Please note that remote control is an optional extra.) To operate, first press the right master switch (located on the right underside of the flame aperture of the product) which is marked (O/I) to the ( I ) position then perform the following actions: FLAME EFFECT ONLY (NO HEAT) Manual –...

  • Page 5: Installation

    INSTALLATION To install the following models – Arizona,Boardway,Corsano,Compton,Compton1000,Empire,Newark,Newark1000,Qube,Tetris,Volante – please see below: Each model is provided with a wall mounting bracket along with x5 screws and wall plugs. PLEASE NOTE: The screws and plugs provided are only suitable for a solid wall fixing.
  • Page 6 INSTALLATION: (Please be aware: that no products should be sealed against the wall/opening as this can effect the performance of the heater unit. This also includes Cordelia/Portia Products.) Volante Product shown as example Wall Bracket Minimum Installation Height: From floor level to bottom edge of product. This suite is supplied with a wall fixing Bracket.
  • Page 7 Installation: Octane/Veyron Suite. (Please be aware: that no products should be sealed against the wall/opening as this can effect the performance of the heater unit.) Fixing point measurements: 645mm From the Base of the suite to the centre of the keyhole slot. 288mm between the keyhole slots.
  • Page 8 Installation: Targa Suite (Please be aware: that no products should be sealed against the wall/opening as this can effect the performance of the heater unit.) The control switches for the Targa suite are located under the hearth shelf on the right hand side. Fig.1 = To remove the glass from the targa suite simply lift from both sides, and pull towards you once the glass has cleared the hearth/shelf.
  • Page 9 MAINTENACE Replacing the bulbs: (Please ensure that the appliance is disconnected from the mains supply before proceeding). (Please note that the below steps do not apply to EVO-FLAME products). Models: Volante/Panamera/Tetris/Targa The suite uses x2 – STD Bayonet 20W Energy saving lamps. (Tetris/Targa Models: Remove glass, To remove the glass simply lift clear of the hearth and pull out from the bottom.) To change the bulbs in the suite you must first remove all pebbles,coals,logs or embers from the orange fuel bed.
  • Page 10 Guarantee: Conditions of warranty: If this appliance should prove to be defective due to faulty design, materials or workmanship within 24 months of purchase, the product will be repaired free of charge, subject to the following conditions: The electric fire shall have been purchased and used solely within the UK and Ireland for domestic purposes and in accordance with the Users operating instructions.

  • Page 11: Extended Warranty

    EXTENDED WARRANTY: In order to qualify for an additional 12 months warranty, Please complete the form below. This form must be submitted no later than 30 - days after the purchase of the product. NAME: ADDRESS: MODEL: SERIAL NO: DATE OF PURCHASE: PURCHASED FROM: ADDRESS: INSTALLATION DATE:...
