Page 1 English English INSETS INSETS INSTRUCTION MANUAL INSTRUCTION MANUAL Ev4i Ev4i Kepler 22 Kepler 22 Strellar Strellar Ev4i4 Ev4i4 Colorado Colorado Sphera Sphera Ev6i Ev6i Oberon Oberon Argenta 16 Argenta 16 Ev6i4 Ev6i4 Topaz Topaz Argenta 22 Argenta 22 INSETS MANUAL ISS. 7 INSETS MANUAL ISS.
Page 2: Table Of Contents
CONTENTS EU Directives and UKCA Standards..............3 Important Information and Health & Safety............4 Components for Insets..................5 Operating Instructions..................6 Installation......................8 Slide in models....................12 Tie-back models..................14 With spacer....................16 Wall-Mounted....................18 Removing the Glass....................20 Fitting the Fascia....................25 Troubleshooting....................28 Warranty.......................29 INSETS MANUAL ISS. 7 INSETS MANUAL ISS.
Page 3: Eu Directives And Ukca Standards
EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances.
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual. Any other use not recommended by the manufacturer may Any other use not recommended by the manufacturer may cause injury to persons, or damage to the appliance.
Page 5: Components For Insets
INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 6: Operating Instructions
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Manual Manual Remote Control Remote Control INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 7 MANUAL OPERATION You can operate your appliance using the manual rocker switches located on the right hand side. Please note there is no manual dimmer control. - To turn on the appliance and activate the flame effect, press the top rocker switch to the I/On position. - To activate the heater at Low Heat, press the middle rocker switch to the I position.
Page 8: Installation
INSTALLATION INSTALLATION INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 9 MODEL DIMENSIONS The model shown in these drawings is a Colorado for illustrative purposes, please refer to the table for your specific models size. INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 10 MODEL DIMENSIONS Width Height Depth Model Overall Insert Overall Insert Overall Insert Frame Colorado 460mm 382mm 605mm 550mm 130mm 75mm 55mm Ev4i 480mm 382mm 590mm 550mm 145mm 75mm 70mm Ev4i4 480mm 382mm 620mm 550mm 145mm 75mm 70mm Ev6i 625mm 382mm 590mm...
Page 11 INSTALLATION PROCESS Sphera, Colorado, Sphera, Colorado, Colorado, Colorado, Ev4i4, Ev4i4, Ev4i, Ev4i4, Ev6i, Ev4i, Ev4i4, Ev6i, Kepler 22 Kepler 22 Ev6i4, Ev6i4, Ev6i4, Kepler 22, Ev6i4, Kepler 22, Topaz Topaz Topaz, Argenta 16, Topaz, Argenta 16, Strellar Strellar Oberon Oberon...
Page 12: Slide In Models
INSTALLATION INSTALLATION Slide in Slide in Ev4i Ev4i Kepler 22 Kepler 22 Argenta 16 Argenta 16 Ev4i4 Ev4i4 Topaz Topaz Argenta 22 Argenta 22 Ev6i Ev6i Colorado Colorado Ev6i4 Ev6i4 Sphera Sphera INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7...
Page 13 INSTALLATION All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting the installation check the dimensions of both the appliance and your opening to ensure that they align well. Please note, if you are installing into an existing chimney breast it is imperative that the flue is adequately blocked off.
Page 14: Tie-Back Models
INSTALLATION INSTALLATION Tie Back Models Tie Back Models Oberon Oberon Strellar Strellar INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 15 INSTALLATION All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting the installation check the dimensions of both the appliance and your opening to ensure that they align well. Please note, if you are installing into an existing chimney breast it is imperative that the flue is adequately blocked off.
Page 16: With Spacer
INSTALLATION INSTALLATION With Spacer With Spacer Colorado Colorado Kepler 22 Kepler 22 INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 17 INSTALLATION To convert your appliance to a free-standing unit you can fit an optional spacer. Before securing the spacer, attach the electrical lead to the inlet at the back bottom corner of the appliance. Once the spacer is fitted it will be more difficult to attach this. Position the spacer at the back of the appliance and line up the three screw holes on both appliance and spacer.
Page 18: Wall-Mounted
INSTALLATION INSTALLATION Wall Mounted Wall Mounted Ev4i4 Ev4i4 Ev6i4 Ev6i4 Topaz Topaz INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 19 INSTALLATION All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting the installation check the dimensions of both the appliance and your opening to ensure that they align well. Once the measurements are confirmed, plug in the appliance and slide it into the prepared opening.
Page 20: Removing The Glass
REMOVING THE GLASS REMOVING THE GLASS Ev4i Ev4i Kepler 22 Kepler 22 Colorado Colorado Ev4i4 Ev4i4 Strellar Strellar Ev6i Ev6i Argenta 16 Argenta 16 Ev6i4 Ev6i4 Argenta 22 Argenta 22 INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 21 Unscrew the two screws, and remove the bottom glass retainer from the appliance. The glass can now be removed from the appliance. To replace the glass, follow the steps in reverse. INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 22 REMOVING THE GLASS REMOVING THE GLASS Sphera Sphera EVONIC - 104 INSTRUCTION MANUAL ISS. 5 EVONIC - 104 INSTRUCTION MANUAL ISS. 5...
Page 23 Unscrew the two screws, and remove the top plate. With the top plate now removed, slide the glass upwards to remove. EVONIC - 104 INSTRUCTION MANUAL ISS. 5 EVONIC - 104 INSTRUCTION MANUAL ISS. 5...
Page 24 FUEL SETS Once your appliance is installed and any front glass is removed you can lay out your fuel set as you wish. Then replace any glass panel by reversing the glass removal steps. Logs White or Beach Pebbles Logs & Beach Pebbles Kindling Set &...
Page 25: Fitting The Fascia
FITTING THE FASCIA FITTING THE FASCIA INSETS MANUAL ISS. 7 INSETS MANUAL ISS. 7 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 26 • Colorado • Ev6i4 • Ev4i • Sphera SLOTTED The Oberon and Strellar cast fascia is secured to the front of the appliance with two top mounted clips and a mounting bracket. Line up the two clips with the top of the mounting bracket and slot them down into the bracket.
Page 27 The cast frame can now be screwed to the appliance using the 2x screws supplied. The screw holes are located at the lower part of the frame. Once these are fitted, the fret panel can be fitted in front of this. INSETS MANUAL ISS.
Page 28: Troubleshooting
TROUBLESHOOTING Applies to; Colorado / Ev4i / Ev4i4 / Ev6i / Ev6i4 / Kepler 22 / Oberon/ Strellar / Topaz / Argenta 16 / Argenta 22 Colorado Blower Access & Clean Scan the QR code to be taken to a video in our maintenance series.
Page 29: Warranty
To receive your Extended Warranty your Evonic Fires product must have been purchased from an authorised stockist within our Retailer Network and your warranty registered with Evonic Fires through the online form - evonicfires.co.uk/register-your-product. The commencement date for the warranty period is the date of purchase.
Page 30 The Evonic Fires Extended Warranty does not affect your statutory rights. CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk www.evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires INSETS MANUAL ISS.
