Summary of Contents for Evonicfires Amathus
- Page 1 English English INSETS INSETS INSTRUCTION MANUAL INSTRUCTION MANUAL Amathus Amathus Ev6i Ev6i Nebraska Nebraska Brooklyn Brooklyn Ev6i4 Ev6i4 Oberon Oberon Colorado Colorado Iowa Iowa Phantom Phantom Detroit Detroit Kansas Kansas Staton Staton Ev4i Ev4i Kepler 22 Kepler 22 Strellar Strellar...
-
Page 2: Table Of Contents
Model Dimensions..................9 Installation Process..................11 Installation (Slide in Models)............... 12 Applies to: Amathus / Brooklyn / Colorado / Detroit / Ev4i / Ev4i4 / Ev6i / Ev6i4 / Iowa / Kepler 22 / Nebraska / Phantom / Staton / Topaz Installation (Tie Back Models).............. -
Page 3: Eu Directives And Ukca Standards
EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances. -
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual. Any other use not recommended by the manufacturer may Any other use not recommended by the manufacturer may cause injury to persons, or damage to the appliance. -
Page 5: Components For Insets
INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Manual Manual Remote Control Remote Control INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... -
Page 7: Manual Operation And Remote Control
MANUAL OPERATION You can operate your appliance using the manual rocker switches located on the right hand side. Please note there is no manual dimmer control. - To turn on the appliance and activate the flame effect, press the top rocker switch to the I/On position. - To activate the heater at Low Heat, press the middle rocker switch to the I position. -
Page 8: Installation
INSTALLATION INSTALLATION INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... -
Page 9: Model Dimensions
MODEL DIMENSIONS The model shown in these drawings is a Colorado for illustrative purposes, please refer to the table for your specific models size. INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... - Page 10 MODEL DIMENSIONS Width Height Depth Model Overall Insert Overall Insert Overall Insert Frame Amathus 506mm 382mm 602mm 550mm 105mm 75mm 30mm Brooklyn 490mm 382mm 605mm 550mm 130mm 60mm 70mm Colorado 460mm 382mm 605mm 550mm 130mm 75mm 55mm Detroit 460mm 382mm...
-
Page 11: Installation Process
INSTALLATION PROCESS Amathus, Brooklyn, Amathus, Brooklyn, Colorado, Detroit, Colorado, Detroit, Amathus, Brooklyn, Amathus, Brooklyn, Ev4i4, Ev4i4, Ev4i, Ev4i4, Ev6i, Ev4i, Ev4i4, Ev6i, Colorado, Detroit, Colorado, Detroit, Ev6i4, Ev6i4, Ev6i4, Iowa, Ev6i4, Iowa, Iowa, Kepler 22, Iowa, Kepler 22, Topaz Topaz... -
Page 12: Installation (Slide In Models)
INSTALLATION INSTALLATION Slide in Slide in Amathus Amathus Ev4i4 Ev4i4 Nebraska Nebraska Brooklyn Brooklyn Ev6i Ev6i Phantom Phantom Colorado Colorado Ev6i4 Ev6i4 Staton Staton Detroit Detroit Iowa Iowa Topaz Topaz Ev4i Ev4i Kepler 22 Kepler 22 INSETS MANUAL ISS. 6 INSETS MANUAL ISS. - Page 13 INSTALLATION All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting the installation check the dimensions of both the appliance and your opening to ensure that they align well. Please note, if you are installing into an existing chimney breast it is imperative that the flue is adequately blocked off.
-
Page 14: Installation Tie Back Models
INSTALLATION INSTALLATION Tie Back Models Tie Back Models Oberon Oberon Strellar Strellar INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... - Page 15 INSTALLATION All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting the installation check the dimensions of both the appliance and your opening to ensure that they align well. Please note, if you are installing into an existing chimney breast it is imperative that the flue is adequately blocked off.
-
Page 16: Installation With Spacer
INSTALLATION INSTALLATION With Spacer With Spacer Amathus Amathus Detroit Detroit Phantom Phantom Brooklyn Brooklyn Iowa Iowa Staton Staton Colorado Colorado Kepler 22 Kepler 22 INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... - Page 17 INSTALLATION To convert your appliance to a free-standing unit you can fit an optional spacer. Before securing the spacer, attach the electrical lead to the inlet at the back bottom corner of the appliance. Once the spacer is fitted it will be more difficult to attach this. Position the spacer at the back of the appliance and line up the three screw holes on both appliance and spacer.
-
Page 18: Installation Wall Mounted
INSTALLATION INSTALLATION Wall Mounted Wall Mounted Ev4i4 Ev4i4 Ev6i4 Ev6i4 Topaz Topaz INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... - Page 19 INSTALLATION All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting the installation check the dimensions of both the appliance and your opening to ensure that they align well. Once the measurements are confirmed, plug in the appliance and slide it into the prepared opening.
-
Page 20: Removing The Glass
REMOVING THE GLASS REMOVING THE GLASS Colorado Colorado Ev4i4 Ev4i4 Kepler 22 Kepler 22 Detroit Detroit Ev6i Ev6i Nebraska Nebraska Ev4i Ev4i Ev6i4 Ev6i4 Strellar Strellar INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... - Page 21 Unscrew the two screws, and remove the bottom glass retainer from the appliance. The glass can now be removed from the appliance. To replace the glass, follow the steps in reverse. INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
-
Page 22: Fuel Sets
FUEL SETS Once your appliance is installed and any front glass is removed you can lay out your fuel set as you wish. Then replace any glass panel by reversing the glass removal steps. Logs White or Beach Pebbles Logs & Beach Pebbles Coals INSETS MANUAL ISS. -
Page 23: Fitting The Fascia
FITTING THE FASCIA FITTING THE FASCIA INSETS MANUAL ISS. 6 INSETS MANUAL ISS. 6 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1... -
Page 24: Magnet Fitting
FITTING THE FASCIA MAGNETS The following models have a fascia attached with magnets; • Amathus • Ev4i4 • Kepler 22 • Topaz • Brooklyn • Ev6i • Nebraska • Colorado • Ev6i4 • Phantom • Ev4i • Iowa • Staton... - Page 25 SLOTTED The Detroit and Strellar cast fascia is secured to the front of the appliance with two top mounted clips and a mounting bracket. Line up the two clips with the top of the mounting bracket and slot them down into the bracket. The cast frame can now be screwed to the appliance using the 2x screws supplied.
-
Page 26: Troubleshooting
TROUBLESHOOTING Applies to; Amathus / Brooklyn / Phantom Blower Access & Clean Scan the QR code to be taken to a video in our maintenance series. Applies to; Amathus / Brooklyn / Phantom Heater Access Scan the QR code to be taken to a video in our maintenance series. - Page 27 This warranty is in addition to and does not affect the purchasers statutory rights of consumers. REGISTER YOUR FIRE To register a product please visit: www.evonicfires.co.uk and complete the fields required under the Register a Product Section. By registering your appliance, an extra 12 months will be added to your warranty.
