Trace Engineering LEGEND II Manual page 78

AWG
14
12
10
8
6
4
2
1
0 (1/0)
00 (2/0)
000 (3/0)
0000 (4/0)
Inverter Typical DC
Model #
L2012 200 Amps
L2512 250 Amps
L3012 300 Amps
"Free air" is defined by the NEC as cabling that is not enclosed in conduit or a raceway. Cables
enclosed in raceways or conduits have substantially lower continuous current carrying ability due to
heating factors.
WK

DIAMETER/mm
1.628
2.052
2.588
3.264
4.115
5.189
6.543
7.348
8.525
9.266
10.404
11.684
Minimum
Amps Fuse Size
250A
300A
400A
AREA/mm² DC Resistance / 1000ft
2.082
3.308
5.261
8.367
13.299
21.147
33.624
42.406
53.482
67.433
85.014
107.219
1 to 3 feet 3 to 5 ft
One Way One Way
00 00
00 0000
0000 0000
3.14
1.98
1.24
0.778
0.491
0.308
0.194
0.154
0.122
0.0967
0.0766
0.0608
5 to 10 ft
One Way
0000
0000
0000
