Summarization of Contents
INSTALLATION
Preparing for Installation
Turn OFF all power to the vending machine and check its orientation and voltage.
Installing the CF8000 to the machine
Mount the CF8000 by hanging it onto three studs on the vending machine after opening the discriminator assembly.
Alignment Checks
Check reject lever operation, coin chute alignment, and coin drop into the cash return cup.
Cable Connection
Connect relevant cables for communication, display, or audit data and secure unused cables.
KEYPAD FUNCTIONS
Keypad Overview and Usage
The keypad features six function buttons and an LCD display for coin dispensing and menu navigation.
GETTING STARTED
Floating the Coin Tubes
Fill coin tubes manually or using Service Mode to calibrate the CF8000 for coin counting.
CF8000 Menu Structure
Describes two methods to access Setup Mode menus: holding the 'Mode' button or selecting 'Setup' via the 'Mode' button.
Alert Messages
Predefined Cassettes
Activate additional payout options by entering the correct 'Cassette Code' for predefined tube cassettes.
SAFETY
National & International Standards Conformance
CashFlow 8000 Series products comply with SELV standards and are Class 3 construction.
Rated Operating Voltage
The operating voltage stated on the product label must be used; do not use other power sources.
Operating Temperature
Ambient operating temperature range is from -15℃ to 70℃.
Dangerous Environments
Do not operate in flammable gases, fumes, or areas with direct water contact.
Routine Maintenance
Maintenance must be performed by trained technicians using mild soap and a damp cloth.
Product Disposal
Do not dispose of any part of the CashFlow 8000 Series by incineration.
