Summarization of Contents
Introduction
Overview of this Manual
Lists the main sections and their corresponding pages for the retrofit process.
Document Conventions
Explains symbols used for warnings, cautions, and notes in the document.
Safety
Provides critical safety warnings before performing maintenance or service.
The Retrofit
Preparation
Steps to prepare the enclosure and system before starting the retrofit.
Data Terminations
Transfer Beacon Wires
Details on transferring beacon wires to the new CEM3 backplane connector.
Cap ETCLink Wires
Instructions for disconnecting and securing ETCLink wires if present.
Backplane Settings
DIP Switch Configuration
How to set DIP switches on the new backplane based on enclosure type.
Change out AF Cards
AF Card Addressing
Guide to setting DIP switches on new Advanced Feature (AF) cards.
Configure the CEM3
Dimmer Module Configuration
Setting up the CEM3 for the specific dimmer module types in the enclosure.
Data Type Configuration
Setting up DMX and sACN data types and enclosure patching.
Panic Configuration
Instructions for programming and verifying the panic connection.
Dimmer Signal Verification
Checking dimmer signal lights after connecting ribbon cables.
Control Source Verification
Confirming that DMX, sACN, Panic, and Preset stations function correctly.
