Kodak I810 - Scanner Firmware - PC Installation Planning Manual page 8

Environment
Safety, regulatory
conformance, and
certifications
Grounding requirements
A-61176 November 2001
Following are environmental considerations:
Heat Dissipation 4009 kj/hour (3800 Btu/hour) maximum
Acoustic noise
Operator position standby mode:
Sound Pressure Level (L
Operator position full system operating mode:
Sound Pressure Level (L
Instantaneous Peak Values >130 dB(C)
Sound Power Level (L
Standby
Full System
NOTE: All data was measured in accordance with DIN 45635, ANSI
S12.10-1985, and ISO 7779 in a hemi-anechoic chamber.
The Kodak i800 Series Scanners conform to all applicable national and
international product safety and electronic emission regulatory
requirements. This includes, but is not limited to, the following:
UL
CUL (CSA 22.2 No. 950 standard)
TUV / GS Mark
C – Tick Mark
EN 55024
EN 55022 Class A
US - FCC, CFR47, part 15, Class A
Canada - ICES 003, Issue 3, Class A
Japan - VCCI Class A
Taiwan - CNS 13438 Class A
Australia / New Zealand - AS/NZ 3548 Class A
CE Mark
Certifying Body Certificate
The i800 Series Scanner can be on the same line as the host PC. The
power cord must be used with a properly grounded outlet (15 amp
duplex outlet). No devices other than the host PC should be on the
same outlet as the scanner.
Power extension cords should not be used with the scanner or the host
PC.
An uninterruptible power supply is acceptable as long as it meets the
minimum power requirements.
):
A
):
A
):
WA
39.8 dB(A)
65.4 dB(A)
None
56.4 dB(A)
72.0 dB(A)
5
