Summarization of Contents
General Safety Regulations
Symbols Used in the Manual
Explains the various symbols used throughout the instruction manual.
Open book symbol with an "i"
Indicates the need to consult the instruction manual for more information.
Open book symbol
Instructs the operator to read the user manual before using the device.
Covered place symbol
Specifies operations that must be performed in a dry, covered area.
Information symbol
Provides additional information to improve device usage.
Warning symbol
Highlights important safety instructions for operator and device.
Danger symbol (corrosive substances)
Warns about corrosive substances and the need for protective gloves.
Danger symbol (battery acid leakage)
Indicates danger from battery acid leakage during recharging.
Danger symbol (moving carriages)
Requires handling the packed product with suitable carriages.
Mandatory room ventilation symbol
Mandates room ventilation during battery recharging.
Symbol indicating the compulsory use of protective gloves
Enforces the use of protective gloves to prevent hand injuries.
Symbol indicating the compulsory use of tools
Informs the operator about the need to use specific tools.
Symbol indicating a treading ban
Prohibits treading on machine components due to injury risk.
Recycling symbol
Instructs to follow environmental regulations for operations.
Disposal symbol
Requires careful reading of sections marked for appliance disposal.
Labels Used on the Machine
Main switch symbol
Indicates the main power switch on the control panel.
Acoustic signalling device control label
Locates the control button for the acoustic signalling device.
Label for detergent solution tap command
Identifies the control lever for the detergent solution tap.
Label indicating the need to read the Use and Maintenance Manual
Reminds the operator to consult the manual before use.
Treading ban label
Marks surfaces that must not be trodden on.
Label warning about the risk of crushed hands
Warns of danger to hands from crushing between surfaces.
Warning label
Advises reading the manual before first-time machine use.
Forbidden to vacuum collect label
Prohibits vacuuming flammable/explosive materials or hot particles.
Battery charging warning label
Advises on proper battery recharging procedures.
Battery charging warning label
Warns of danger from flammable gases during battery charging.
Solution tank filter daily care warning label
Reminds to clean the solution tank filter after each use.
Vacuum motor filter label
Identifies the vacuum motor intake air filter and cleaning reminder.
Braking system oil level check label
Reminds to check the braking system oil level.
Service brake pedal positioning label
Indicates the position of the service brake pedal.
Label indicating maximum temperature for filling the solution tank
Specifies the maximum temperature for filling the solution tank.
Scrubbing brush head in motion danger warning label
Warns of the brush head's potential for sideways movement.
Symbols Used on the Machine
Recovery tank drainage hose symbol
Identifies the recovery tank's drainage hose.
Solution tank drainage cap symbol
Identifies the solution tank's drainage cap.
Label indicating machine direction selector button
Indicates the machine direction selector button near the steering wheel.
Courtesy lights (optional) control label
Locates the control button for optional courtesy lights.
Spray gun (optional) position label
Identifies the support for the optional spray gun.
Liquid vacuum wand kit (optional) position label
Identifies the compartment for the optional liquid vacuum wand kit.
Label indicating the position of the detergent tank (CDS versions)
Shows the location of the detergent tank for CDS versions.
Label indicating positioning of the cornering speed adjustment sensor
Explains correct positioning of the cornering speed sensor.
Label indicating percentage of detergent use (CDS versions)
Provides usage instructions for detergents in CDS versions.
Water system usage warning label (CDS versions)
Warns users to read the manual for CDS automatic detergent dosing system.
pH label (CDS versions)
Indicates the pH range for detergents used in CDS versions.
Work
Drive Select Selector
Explains how to select the different working modes of the machine.
Adjustment Interventions
Adjusting the Squeegee Body's Rubber Blades
Guides on adjusting the squeegee body's rubber blades for proper floor contact.
