Summarization of Contents
Instrument Description and Care
1.1. Instrument Components
Detailed description of parts for S1 TITAN and CTX.
1.2. TRACER 5 Collimators and Filters
Description and replacement of TRACER 5 collimators/filters.
1.3. General Care and Maintenance
Guidelines for instrument upkeep and cleaning.
1.4. Changing Windows
Procedure for replacing detector windows on instruments.
1.5. Power Sources
Information on batteries, chargers, and power management.
1.6. Contacting Bruker
Contact details for technical support and service.
Radiation Safety
2.1. Radiation Profile – S1 TITAN
Radiation measurements and data for S1 TITAN.
2.2. Radiation Profile – TRACER 5
Radiation measurements and data for TRACER 5.
2.3. Radiation Profile – CTX
Radiation measurements and data for CTX.
2.4. Precautions
Important safety warnings and handling instructions.
2.5. Safety Features
Instrument interlocks and built-in safety mechanisms.
Starting Up
Powering On and Initialization
Steps to power on the analyzer and its boot process.
Logging In
User authentication process and screen descriptions.
Powering Off
Procedure for safely shutting down the instrument.
Interface Elements
Overview of status bar, icons, and keyboards.
APPLICATION Button
Selecting an Application
Choosing the correct analysis type for the sample.
Spectrometer Mode Settings
Configuring settings for Spectrometer Mode.
METHOD Button
Selecting a Method
Choosing analysis methods or calibrations.
SETTINGS Button
Default Settings and Measurement Phases
Configuring measurement duration and phases.
Trigger Options
Manual vs. Auto trigger settings.
SETTINGS Button – Spectrometer Mode
Standard Spectrometer Settings
Selecting pre-defined spectrometer configurations.
Custom Spectrometer Settings
Adjusting spectrometer parameters like kV, µA, and filters.
DISPLAY Button
Selecting Display Options
Choosing how measurement results are presented.
8.1. Display Settings
Detailed configuration of result display units and format.
8.2. Element Display Order
Customizing the order of elements in results.
8.3. Grade ID Settings and More
Additional options for result screen customization.
Utilities Button
9.1. Back Up Data
Copying, moving, or deleting measurement data.
9.2. Remote Control
Enabling and configuring remote operation.
Edit Info Button
Labeling Assays
Naming and describing samples for analysis records.
Results
Reviewing Past Results
Accessing and viewing stored assay results.
Result Data Details
Understanding ID match, columns, and sorting.
11.1. Spectrum
Viewing and analyzing spectral data.
11.2. Averaging
Calculating averages of multiple measurements.
Quality Check
Instrument Calibration Verification
Procedure for checking instrument calibration accuracy.
Appendix A: Additional TRACER 5 Radiation Profile Test Results
TRACER 5 Radiation Data
Detailed radiation test results for TRACER 5.
Appendix B: S1 TITAN Specifications
S1 TITAN Model Specifications
Technical specifications for various S1 TITAN models.
Appendix C: TRACER 5 Specifications
TRACER 5 Specifications
Technical specifications for TRACER 5 models.
Appendix D: CTX Specifications
CTX Specifications
Technical specifications for CTX models.
