DEXAPLAN WA 620 Manual

Overflow Alarm
Water Alarm WA 620
A
7
6
5
C
10
11
Operating and safety instructions
Introduction
Read through these operating instructions fully and carefully. The operating instructions belong to this
product and contain important points concerning bringing the appliance into service and its operation.
Always pay attention to all safety instructions. Should you have any questions or be unsure about
operating the appliance - ask a specialist, inform yourself on the internet under www.dexaplan.com, or
get in touch with the service office. Keep these instructions in a safe place and should the need arise
pass them on to a third party.
Proper use
This water alarm consists of an alarm unit and a sensor connected to it. It can be used to a monitor for
escaping water from e.g. washing machines, dishwashers or water pipes as well as to let you know
whether a container is filled to the desired level e.g. a bath tub.
warning signal or with a melody.
The appliance is designed for operation indoors in private households only. A 9 volt block battery is the
only power supply permitted.
Any other use or change of the appliance is improper use. No liability shall be assumed for
consequential damage as well as damage which is caused by improper use.
This appliance is not intended to be used by people (including children) with restricted physical, sensory
or mental capacities, or a lack of experience and/or knowledge, unless they are supervised by or receive
instructions how to use the appliance from a person responsible for their safety.
Children must be supervised in order to ensure that they do not play with the appliance.
Where liability is not expressly stipulated by law, claims for damages are ruled out, particularly those for
compensation for damage to persons or property, which occur outside the appliance due to non-
functioning or incorrect functioning.
B
1
8
2
3
4
The appliance notifies you with a loud
Included items
GB IE
After unpacking immediately check that the delivery is complete and that the appliances are
undamaged.
1 Alarm unit with connecting cable, approx. 1 m long, with attached sensor
2 Screws (in the battery compartment)
9
2 Plugs Ø 5 mm (in the battery compartment)
1 Operating instructions
Features and equipment
Front sides of the alarm unit and sensor (see diag. A)
1 Alarm unit
2 Loudspeaker
3 Switch
4 Battery compartment cover
5 Connecting cable
6 Sensor contacts
7 Sensor
Reverse sides of the alarm unit and sensor (see diag. B)
8 Attachment holes
L126
9 Sucker
Open battery compartment (see diag. C)
10 Battery connector
11 Battery compartment
Technical data
Operating voltage:
Current draw:
Battery:
Acoustic alarm:
Battery warning:
Temperature range:
Housing dimensions:
Weight:
Safety instructions
Explanation of symbols and terms used:
Danger!
Attention!
Danger to life and risk of injury!
!
Do not leave small children unsupervised with the appliance, packing material or small parts!
Otherwise there is a danger to life through suffocation!
!
Attention! Loud warning signal! Avoid operation close to ears because otherwise severe hearing
damage can occur.
!
Do not damage any gas pipes, or electricity or telecommunication cables when fastening!
Otherwise there is a danger to life or risk of injury or damage!
!
Make sure that the battery is not short-circuited, nor thrown into fire. It may not be recharged.
There is a danger to life through explosion.
9 V DC
max. 130 mA
9-V-Block 6LR61, alkaline (not supplied)
Warning signal (approx . 98 dB(A) / 1 m)
Melody (approx. 90 dB(A) / 1 m)
two short bleeps approx. every 2 minutes
+1 °C to +40 °C
approx. 56 x 104 x 24 mm
approx. 65 g (without battery)
If this point is not heeded life and health is endangered.
If this point is not heeded material assets are endangered.
