Installation and Assembly:
Structural Round Ceiling Plate
Model: ELPMBP03
Manufactured by Peerless Industries, Inc.
3215 W. North Ave. • Melrose Park, IL 60160 • (800) 865-2112 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com
This product is UL Listed. It must be
installed by a qualified professional
R
installer.
Maximum UL Load Capacity: 150 lb (68 kg)
ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08
Advertisement
Table of Contents
Related Manuals for Epson ELPMBP03 - Structural Round Ceiling Plate
Summary of Contents for Epson ELPMBP03 - Structural Round Ceiling Plate
- Page 1 Installation and Assembly: Structural Round Ceiling Plate Model: ELPMBP03 This product is UL Listed. It must be installed by a qualified professional installer. Maximum UL Load Capacity: 150 lb (68 kg) Manufactured by Peerless Industries, Inc. 3215 W. North Ave. • Melrose Park, IL 60160 • (800) 865-2112 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08...
-
Page 2: Table Of Contents
NOTE: Read entire instruction sheet before you start installation and assembly. WARNING • Do not begin to install your product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, call Peerless customer care at 1-800-729-0307. -
Page 3: Parts List
Before you begin, make sure all parts shown are included with your product. Parts List Description Qty. Part # A round ceiling plate 055-2798 B #14 x 2.5" wood screw 5S1-015-C04 C M5 x .8 x 10 mm phillips screw 520-2005 D M5 x .8 x 10 mm socket pin screw 520-2031... -
Page 4: Extension Column And Flush Mounting Applications
Place grommet (F) into hole of ceiling plate (A). NOTE: Make sure grommet overlaps retaining collar. Grommet may require some force to fit in hole and will appear slightly deformed. RETAINING COLLAR WARNING • For safety, extension column must be locked to threaded fitting with screw. Extension Column Applications Insert end of extension column into threaded fitting of ceiling plate (A). -
Page 5: Installation To Wood Joist Finished Ceilings, Exposed Wood Joists Or Wood Beam Ceilings
Installation to Wood Joist Finished Ceilings, Exposed Wood Joists, or Wood Beam Ceilings WARNING • Installer must verify that the supporting surface will safely support the combined load of the equipment and all attached hardware and components. • Tighten wood screws so that ceiling plate is firmly attached, but do not overtighten. Overtightening can damage the screws, greatly reducing their holding power. -
Page 6: Installation To Solid Concrete
Installation to Solid Concrete WARNING • Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor. • Make sure that the supporting surface will safely support the combined load of the equipment and all attached hard- ware and components. -
Page 7: Warranty Information
LIMITED FIVE-YEAR WARRANTY www.peerlessmounts.com © 2007 Peerless Industries, Inc. ISSUED 03/17/06 LIT-0190E 7 of 7 ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08 Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870. © 2008, Peerless Industries, Inc. All rights reserved. All other brand and product names are trademarks or registered trademarks of their respective owners.
