Summarization of Contents
Contact and Compliance Information
Contact Information
Provides contact details for Enphase Energy and support channels.
FCC Compliance
Details the FCC rules and regulations this equipment complies with.
Technical Data
Technical Considerations
Key considerations for pairing PV modules with the M215 microinverter.
M215 Microinverter Specifications
Detailed performance and operational parameters for M215 microinverter models.
Engage Cable Specifications
Technical details and ratings for the Enphase Engage Cable.
Important Safety Information
Read this First
Crucial initial instructions for safe installation and maintenance of the M215.
Safety and Advisory Symbols
Description of symbols indicating hazardous conditions and important safety advice.
Safety Instructions
Essential safety guidelines for handling and installing the Enphase Microinverter.
The Enphase Microinverter System
How the Microinverter Works
Explains how each microinverter maximizes energy production from a single PV module.
System Monitoring
Describes how the Envoy Gateway reports data to Enlighten for performance monitoring.
Optimal Reliability
Highlights the inherent reliability of microinverter systems and NEMA 6 rating.
Planning for Microinverter Installation
Compatibility and Capacity
Details compatibility with PV modules and system capacity considerations.
Mechanical Compatibility
Lists model numbers and their corresponding PV module connector types.
Installation Planning Details
Grounding Considerations
Explains grounding requirements for different M215 models and methods.
Utility Service Requirements
Specifies voltage requirements for 240 VAC split phase and 208 VAC three-phase services.
Branch Circuit Capacity
Outlines the maximum number of M215s per branch circuit with a 20A breaker.
Commissioning and Operation
Energize the System
Steps to safely power up the Enphase Microinverter system.
Check the Envoy's Progress
Procedure to verify the Envoy's detection of microinverters and communication.
Configure the Grid Profile
Instructions for setting system grid profiles based on local utility requirements.
Virtual Array Configuration
Build the Virtual Array
Guide to creating a virtual representation of the PV array in Enlighten.
Troubleshooting
Status LED Indications and Error Reporting
Explains LED status indicators for startup and post-startup error reporting.
DC Resistance Low – Power Off Fault
Details troubleshooting steps for the DC Resistance Low fault.
Microinverter Faults
GFDI Fault
Troubleshooting procedures for Ground Fault detection (GFDI) errors.
Troubleshoot an Inoperable Microinverter
Step-by-step guide to diagnose and fix microinverters not producing power.
Microinverter Maintenance Procedures
Disconnect a Microinverter
Procedure for safely disconnecting a microinverter from the system.
Install a Replacement Microinverter
Instructions for replacing a faulty microinverter with a new unit.
Engage Cable Planning
Selecting Cable Type
Details available Enphase Engage Cable types and their applications.
Connector Spacing Options
Explains connector spacing options for portrait and landscape PV module orientations.
Engage Cable Ordering and Planning
Voltage Type and Conductor Count Options
Describes voltage types and conductor counts for Engage Cable.
Cabling Length Options
Lists available Engage Cable lengths and connector counts.
Planning for Cable Lengths and Type
Considerations for planning cable routes and selecting the correct cable type.
