TOYOTA
Preparation
Part Number:
PU100-3415S-01, PK3B1-34H5H (Short)
PU100-3415R-01, PK3B1-34H6H (Reg.)
PU100-3415L-01, PK3B1-34H8H (Long)
Kit Contents
Item #
Quantity Reqd.
1
1
2
2
2
4
1
Hardware Bag Contents
Item #
Quantity Reqd.
1
1
2
1
3
1
4
1
5
1
Additional Items Required For Installation
Item #
Quantity Reqd.
1
1
2
3
Conflicts
Bed Divider (PT767 34070) & Bed Liners that are not
compatible with Toyota accessory rails
GoPro® mount
General Applicability
All Tundra models with accessory bed rails
Recommended Sequence of Application
Item #
Accessory
1
Bed Liner
2
Tonneau Cover
3
Accessory Rails
Issue: C 04/18/2017
TUNDRA
Description
Tonneau Cover
Side Rails (1 left, 1 right)
Drain Tubes
Hardware Bag
Description
User Manual
Clamp Bracket
(10pc Short Bed, 12pc Regular
Bed, 16pc Long Bed)
T30 Torx, M6 x 1.0 x 30mm
Mounting Hardware
(10pc Short Bed, 12pc Regular
Bed, 16pc Long Bed)
Foam Seal Roll
Hex Key
Description
Bed Rails (if the vehicle is not
already equipped)
*Mandatory
Page 1 of 11 pages
2016 -
Recommended Tools
Personal & Vehicle
Protection
Safety Glasses
Wrist & Belt Buckle
Protection
Special Tools
Installation Tools
Torx Socket
Torque Wrench
Ratchet
Ratchet Extension
Drill
Drill Bit
Tape Measure
Scissors
Screwdriver
Plastic Mallet
Special Chemicals
Vehicle Service Parts
Item #
Quantity Reqd.
1
2
3
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
SAFETY TORQUE: This mark indicates that torque is
related to safety.
TONNEAU COVER
Notes
Notes
Notes
T-30 (Hardened), 3/8" Drive
200 N-m, 150 in-lbf, 3/8"
Drive
3/8" Drive
Short, 3/8" Drive
3/4" dia.
Phillips #2
Notes
(may be required for reassembly)
Description
DIO
Advertisement
Related Manuals for Toyota PK3B1-34H5H
Summary of Contents for Toyota PK3B1-34H5H
- Page 1 Item # Quantity Reqd. Description Conflicts Bed Divider (PT767 34070) & Bed Liners that are not compatible with Toyota accessory rails GoPro® mount General Applicability Legend All Tundra models with accessory bed rails STOP: Damage to the vehicle may occur. Do not Recommended Sequence of Application proceed until process has been complied with.
- Page 2 Vehicle Disassembly/Reassembly (panel removal, part storage, etc.). Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.). Please see your Toyota dealer for a copy of this document. 1. Prepare for the Installation. (a) Before working on the vehicle, protect the truck bed with covers.
- Page 3 TOYOTA TUNDRA 2016 - TONNEAU COVER Procedure Plastic mallet (4) From the back side of the accessory rail, use a plastic mallet to lightly tap the locator peg towards the larger opening in the “keyhole” in the rail (Fig. 1-3).
- Page 4 NOTE: The top of the rail must contact the truck bed side wall to ensure a good seal (Fig. 2-7). CAUTION: If the vehicle is equipped with a Toyota bed liner, ensure that the liner is not sandwiched between the clamps and the truck Fig. 2-7 bed.
- Page 5 NOTE: Make sure the tube covers all the three lines around the drain cap. NOTE: If the vehicle is NOT equipped with a Toyota bed liner or is equipped with a spray-on bed liner, continue to Step 2(i). If the vehicle is Fig. 2-10 equipped with a Toyota bed liner, skip to Step 2(m).
- Page 6 (Fig. 2-11). (l) Skip to Step 3. Fig. 2-11 (m) If the vehicle has a Toyota bed liner, route the drain tube through the provided hole (Fig. 2-12). 3. Reinstall the Factory Bed Rails onto the Fig.
- Page 7 TOYOTA TUNDRA 2016 - TONNEAU COVER Procedure 4. Install the Foam Seal. (a) Clean the top surface before applying the seal. (b) Place the included foam seal on the front lip of the truck bed (adhesive side down) below the cab rear window from the driver side bed rail cap to the passenger side bed rail cap (Fig.
- Page 8 TOYOTA TUNDRA 2016 - TONNEAU COVER Procedure (c) Place the center panel down first, being sure to engage the mounting hooks in-between the two rearmost retaining pins on both side rails (Fig. 5-3). Fig. 5-3 (d) Attach the safety cables to the underbody rails on both the driver and passenger sides (Fig.
- Page 9 TOYOTA TUNDRA 2016 - TONNEAU COVER Procedure (f) Visually confirm that the front latches are aligned with the pins in the side rails (Fig. 5- 7) and gently lower the cover to ensure that nothing contacts and causes damage. Slight...
- Page 10 TOYOTA TUNDRA 2016 - TONNEAU COVER Procedure (h) With the tailgate open, unfold the tail panel into the closed position and push it down onto the truck bed (Fig. 5-12 & Fig. 5-13). Fig. 5-12 Fig. 5-13 6. Check the Tonneau Cover for Fit.
- Page 11 Safety cables attached to tonneau panel Liner is not sandwiched between the clamps and the truck bed If the vehicle is equipped with a Toyota bed liner, ensure that the liner is not sandwiched between the clamps and the truck bed...
