TOYOTA
RAV4 (Gas Only)
Preparation
Part Number: PT925-42160
Kit Contents
Item #
Quantity Reqd.
1
1
2
1
3
1
4
1
5
2
6
2
7
1
8
1
9
1
10
1
11
1
Hardware Bag Contents
Item #
Quantity Reqd.
1
2
2
2
3
2
4
2
5
6
6
4
7
4
8
8
9
4
Additional Items Required For Installation
Item #
Quantity Reqd.
1
2
3
4
Conflicts
Hybrid & Adventure Package Models
General Applicability
2016 & later RAV4 gas models, except Adventure Package
Issue: C 07/27/2017
2016 - 2018
Description
LH Board Assembly
RH Board Assembly
LH Rear Mounting Bracket
RH Rear Mounting Bracket
Front Mounting Bracket
Front Pinch Weld Bracket
Jack Block
Jack Decal
Pinch weld Drill Templates
Hardware Bag
Owner's Manual Decal
Description
M12 Frame Locking Bolt
M12 Serrated Flange Nut
M8 U-Bolt
M8 Carriage Bolt
M8 Serrated Flange Nut
M5 SEMS bolt w/lead in tip
M5 Flange Nut
M8 Serrated Flange Bolt
#12 x ¾" Tech Screw
Description
Page 1 of 14 pages
Recommended Tools
Personal & Vehicle
Protection
Special Tools
Installation Tools
Ratchet
Shallow Sockets
Deep Sockets
Extension
Socket Adapter
Combination Wrench
Torque Wrench –
Ft Lbs / Nm
Center Punch
Drill Motor
Drill Bit
Plastic Scraper Tool
Plastic pry tool
Allen Socket
Deburring Tool
Special Chemicals
Sealer
Recommended Sequence of Application
Item #
Accessory
1
Mudguard
2
Running Boards
*Mandatory
Vehicle Service Parts
(may be required for reassembly)
Item #
Quantity Reqd.
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
SAFETY TORQUE: This mark indicates that torque is
related to safety.
RUNNING BOARDS
Notes
Notes
Notes
3/8"
8mm, 10mm (1/4" Drive)
13mm, 18mm (3/8" Drive)
3" long (⅜" Drive)
6" long (¼" Drive)
3/8" Drive to 1/4" Drive
8mm
3/8" Drive
(3-60 ft lbs
4-81 Nm)
/
3/8" Drive
5.5mm Bit
(7/32")
3mm (1/4" Drive)
Notes
3M Pro Auto Body Sealant
Description
DIO
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Toyota PT925-42160
Summary of Contents for Toyota PT925-42160
- Page 1 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Preparation Part Number: PT925-42160 Kit Contents Recommended Tools Item # Quantity Reqd. Description Personal & Vehicle Notes LH Board Assembly Protection RH Board Assembly LH Rear Mounting Bracket Special Tools Notes...
- Page 2 Vehicle Disassembly/Reassembly (panel removal, part storage, etc.). • Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.). Please see your Toyota dealer for a copy of this document. 1. Prepare for the Installation. (a) Lay out the parts to check for damage.
- Page 3 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure 2. Remove Parts and Drill. (a) Open all four doors before lifting the vehicle to allow access for drilling the pinch welds. 10 mm socket & ratchet, plastic pry tool (b) Remove and discard the left and right rear diffusers.
- Page 4 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure (f) Locate the front and rear pinch weld drill Forward template positions (Fig. 2-4). (g) Remove the pinch weld drill template from the white paper backing and install the template along the jacking point of the pinch weld.
- Page 5 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure 3. Install the Front Left Hand Bracket to the Vehicle. NOTE: If needed, remove any OEM pinch weld sealant that may interfere with the proper installation of mounting hardware and/or components.
- Page 6 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure (e) Swing the plastic retaining clip over to the other side of the U-bolt and connect the secondary retaining notch to the U-bolt (Fig. 3-4). Fig. 3-4 (f) With the plastic U-bolt retaining clip firmly...
- Page 7 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure (l) Torque the M8 carriage nut to 23 N-m (17 ft- lb). Torque: 23 N-m (17 ft-lb) (m) Torque both front bracket U-bolts in 3 steps: 7 N-m (60 in-lb), 14 N-m (10 ft-lb) and a final torque of 23 N-m (17 ft-lb).
- Page 8 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure (c) Insert the short side up into the hole completely and slide the bolt forward (Fig. 4- NOTE: Verify that the frame locking bolt tab is completely inserted into the mounting hole before continuing to the next step.
- Page 9 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure 5. Install the Left Hand Running Board to the Bracket. NOTE: The running boards are side specific. The larger end cap goes to the FRONT of the vehicle. NOTE: If the vehicle does not have mudguards, skip to Step 5(d).
- Page 10 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure (g) Set the running board onto the brackets, tilt the board and slide it inward (Fig. 5-5). Fig. 5-5 (h) Align the rear edge of the running board with the edge of the fender flare (Fig. 5-6).
- Page 11 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure 7. Re-Torque all Hardware. (a) Starting with the left hand side, perform a re- torque as follows: (b) From the inside, torque the front M5 bolt. Torque: 5 N-m (48 in-lb) (c) Torque the M8 carriage nut.
- Page 12 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure 9. Place the Jack Warning Sticker. (a) Remove the jack from the rear cargo compartment. NOTE: Make sure the jack is free of dirt and grease. (b) Place the yellow warning sticker 3mm from the top edge of the jack arm (Fig.
- Page 13 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Procedure 11. Place the Owner’s Manual Sticker. (a) Retrieve the vehicle Owner’s Manual from the glove compartment. (b) Go to the Red Section: “WHEN TROUBLE ARISES”. (c) Locate the “If you have a flat tire” page.
- Page 14 TOYOTA RAV4 (Gas Only) 2016 - 2018 RUNNING BOARDS Checklist - these points MUST be checked to ensure a quality installation. Check: Look For: Accessory Function Checks Inspect bolt torque Verify all of the torque values Top left of Red Section: “WHEN Warning decals have been placed in TROUBLE ARISES”...
