FRONT FABRIC & CANVAS SEAT COVERS
(FRONT SIDE SEAT AIRBAG COMPATIBLE)
FITTING INSTRUCTIONS
KIT CONTENTS
Item Name
Driver Side Cover
Passenger Side Cover
Headrest Cover
FITTING INSTRUCTION
PZQ22-89220-250 (FABRIC),
PZQ22-89320-350 (CANVAS)
Qty
1
1
2
Issue: 2 - 27-07-2015
FITTING TIME
20 MINUTES
HILUX
2015 PRODUCTION ONWRDS
PART NUMBER: PZQ22-89220 (FABRIC)
PZQ22-89230 (FABRIC)
PZQ22-89240 (FABRIC)
PZQ22-89320 (CANVAS)
PZQ22-89330 (CANVAS)
PZQ22-89340 (CANVAS)
FORTUNER
2015 PRODUCTION ONWRDS
PART NUMBER: PZQ22-89250 (FABRIC)
PZQ22-89350 (CANVAS)
Page 1 of 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Toyota PZQ22-89220
Summary of Contents for Toyota PZQ22-89220
- Page 1 FRONT FABRIC & CANVAS SEAT COVERS FITTING TIME (FRONT SIDE SEAT AIRBAG COMPATIBLE) 20 MINUTES FITTING INSTRUCTIONS HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220 (FABRIC) PZQ22-89230 (FABRIC) PZQ22-89240 (FABRIC) PZQ22-89320 (CANVAS) PZQ22-89330 (CANVAS) PZQ22-89340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250 (FABRIC)
- Page 2 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) General Notes PZQ22-89350(CANVAS) Please read these instructions carefully before installation, paying special attention to all Note & Caution notes. Failure to do so may result in damaged parts or injury to the installer or customer.
- Page 3 FABRIC Care Instructions PZQ22-89350(CANVAS) When soiled or stained, we recommend Toyota Genuine car seat covers to be hand washed in warm water. For stubborn stains, a reputable pre-wash stain remover can be sprayed onto stained area prior to washing.
- Page 4 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 1. FRONT COVER INSTALLATION Remove headrests VIEW Figure 1. Step 2. Release flap Figure 2. Step 3. Locate driver side cushion cover.
- Page 5 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 4. Loosely install backrest cover Don’t pull too hard on cover. Threads can break. Important Figure 4. Step 5. From button side, push cover under head rest guide hole (1) then work around the guide to other side (2).
- Page 6 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 7. Check airbag seam alignment Seat Cover Airbag Seam located here Important Seat Airbag Seam located here Important Figure 7. Step 8.
- Page 7 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 9. CANVAS ONLY: MAP POCKET INSTALLATION Pull Map Pocket from locations shown to move zip closer Figure 9.1. Figure 9.2. Step 10.
- Page 8 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 12. Fold cover over seat cushion Figure 12. Step 13. Pull rod through from straps Don’t pull on tape. Threads can break.
- Page 9 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 15. Align outside of cushion cover, insert side rod and tuck sides in Figure 15.1. Figure 15.2. Step 16. Align front of cushion cover Figure 16.
- Page 10 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) For Fabric Headrest Cover Installation go to Step 22 Note Step 18. CANVAS HEADREST COVER INSTALLATION Slide headrest cover over headrest Don’t pull from side flaps Important Figure 18.
- Page 11 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 21. Attach tapes under headrest Go to Step 25 Note Figure 21. Step 22. FABRIC HEADREST COVER INSTALLATION Slide headrest cover over headrest Don’t pull from side flaps...
- Page 12 HILUX 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89220-240 (FABRIC) PZQ22-89320-340 (CANVAS) FORTUNER 2015 PRODUCTION ONWRDS PART NUMBER: PZQ22-89250(FABRIC) PZQ22-89350(CANVAS) Step 24. Align flaps and attach tapes under headrest Figure 24. Step 25. Install headrests VIEW Figure 25. Page 12 of 12...
