TOYOTA
Preparation
Part Number:
PU100-3415S-01, PK3B1-34H5H (Short)
PU100-3415R-01, PK3B1-34H6H (Reg.)
PU100-3415L-01, PK3B1-34H8H (Long)
Kit Contents
Item #
Quantity Reqd.
1
1
2
2
2
4
1
Hardware Bag Contents
Item #
Quantity Reqd.
1
1
2
1
3
1
4
1
5
1
Additional Items Required For Installation
Item #
Quantity Reqd.
1
1
2
3
Conflicts
Bed Divider (PT767 34070) & Bed Liners that are not
compatible with Toyota accessory rails
GoPro® mount
General Applicability
All Tundra models with accessory bed rails
Recommended Sequence of Application
Item #
Accessory
1
Bed Liner
2
Tonneau Cover
3
Accessory Rails
Issue: C 04/18/2017
TUNDRA
Description
Tonneau Cover
Side Rails (1 left, 1 right)
Drain Tubes
Hardware Bag
Description
User Manual
Clamp Bracket
(10pc Short Bed, 12pc Regular
Bed, 16pc Long Bed)
T30 Torx, M6 x 1.0 x 30mm
Mounting Hardware
(10pc Short Bed, 12pc Regular
Bed, 16pc Long Bed)
Foam Seal Roll
Hex Key
Description
Bed Rails (if the vehicle is not
already equipped)
*Mandatory
Page 1 of 11 pages
2016 -
Recommended Tools
Personal & Vehicle
Protection
Safety Glasses
Wrist & Belt Buckle
Protection
Special Tools
Installation Tools
Torx Socket
Torque Wrench
Ratchet
Ratchet Extension
Drill
Drill Bit
Tape Measure
Scissors
Screwdriver
Plastic Mallet
Special Chemicals
Vehicle Service Parts
Item #
Quantity Reqd.
1
2
3
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
SAFETY TORQUE: This mark indicates that torque is
related to safety.
TONNEAU COVER
Notes
Notes
Notes
T-30 (Hardened), 3/8" Drive
200 N-m, 150 in-lbf, 3/8"
Drive
3/8" Drive
Short, 3/8" Drive
3/4" dia.
Phillips #2
Notes
(may be required for reassembly)
