Dts Thx 5.1 - Lexicon DC-1 - ADDENDUM Owner's Manual Addendum

DC-1 Digital Controller
This Effect provides THX 5.1 Cinema enhancements for film soundtracks
recorded in the DTS format. This processing compensates for the acoustical
differences between large mixing theaters and the typically smaller home
environment. In this effect the side and rear speakers are driven in parallel
when you designate side speakers as STANDARD (LARGE or SMALL) in
the Speaker Configuration menu. When DIPOLE is selected, the rear
outputs will mute.
Parameter
RE-EQUALIZER
SIDE LEVEL
LFE MIX LEVEL
SUBWOOFER LVL
CUSTOM
RE-EQUALIZER equalizes the left, center, and right channel outputs to
match the overall frequency balance of the original recording. Without this
re-equalization, many films and some television programs will sound too
bright.
SIDE LEVEL controls the output level of the side speakers. Use this control
in conjunction with SURROUND LEVEL to achieve the optimum balance
between the side and rear speakers.
LFE MIX LEVEL allows separate level attenuation of the LFE channel,
which is ultimately mixed to the subwoofer output. As the bass from as
many as five other channels is added to the LFE, it can significantly raise
subwoofer output levels — and create the risk of damage to a system.
Careful adjustment of this parameter will allow you to achieve proper tonal
balance and reduce the risk of damage.
SUBWOOFER LVL boosts or cuts the subwoofer output level. Although the
normal subwoofer level is set during the calibration procedure, with some
recordings it may be desirable to increase or decrease this deep bass level.
Initial Value
On
0.0dB +5 to -80dB, Off
+0.0dB -20.0dB to 0.0dB
+0dB

DTS THX 5.1

DTS THX 5.1 Parameters
Range
On, Off
-5 to +5dB
DC-1Effects
39
