MC-8/MC-8B
Serial Protocol Definition
Software Version 2.0
Protocol Version:
Major Rev 1
Minor Rev 7
NOTE: The Parameter ID list in the rear pages of this document identifies specific commands to the version 2.00
software. However, the descriptions and information in the rest of the document apply to all versions of the
software currently released.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexicon MC-8

Summary of Contents for Lexicon MC-8

  • Page 1 MC-8/MC-8B Serial Protocol Definition Software Version 2.0 Protocol Version: Major Rev 1 Minor Rev 7 NOTE: The Parameter ID list in the rear pages of this document identifies specific commands to the version 2.00 software. However, the descriptions and information in the rest of the document apply to all versions of the...
  • Page 2 Lexicon “Lexicon” and the Lexicon logo are registered trademarks of Harman International Industries. U.S. patent numbers and other worldwide patents issued and pending. Windows® is a registered trademark of Microsoft Corporation. © 2005 Harman International Industries, Incorporated. All rights reserved.

  • Page 3: Table Of Contents

    Send Display String Command 6.3.11 MC-8 Get Parameter Definition by Id 6.3.12 MC-8 Set Parameter Value by Id 6.3.13 MC-8 Set Parameter Value by Id, No Run 6.3.14 MC-8 Get Unit Configuration 6.3.15 MC-8 Send IR Command 6.3.16 MC-8 Get Parameter Value by Id 6.3.17...
  • Page 4 Lexicon 6.3.26 MC-8 Set Zone2 Volume 6.3.27 MC-8 Set Zone2 Left/Right Balance 6.3.28 MC-8 Get Input Name by Id 6.3.29 MC-8 Set Input Name by Id Appendix A Command Codes Appendix B Error Codes Appendix C MC-8 IR Codes Appendix D MC-8 Input Ids...

  • Page 5: Documents

    The intention of the MC-8 serial port and protocol communication is for an external connected HOST to control and obtain status from the MC-8. The protocol has been designed to focus on two specific goals. The first is HOST uploading and downloading of MC-8 configuration, and system/effect setups. The second is HOST control of basic user adjustable parameters (i.e.

  • Page 6: Physical Layer

    4.4 MC-8 Receive Buffer The MC-8 has an internal receive buffer. The buffer is 256 Bytes and will transmit a NAK packet with an error code of DC_ERR_BUFFER_FULL to the HOST if the buffer is full. If the buffer is full, all data transmitted to the MC-8 will be ignored.

  • Page 7: Mc-8 Hardware Verification

    D9 connector(s) on the rear panel of the MC-8 labeled “RS232”. The wraparound plug shorts pins 2 to 3, allowing for the MC-8 to receive the signal it is transmitting. Once installed, power cycle the MC-8 and verify the following message is displayed on the FPD: This message is displayed for about 2 seconds before entering normal operating mode.

  • Page 8: Application Layer

    The notification packets are defined as follows: 6.1.1 Wakeup Notification By transmitting the Wakeup Notification, the MC-8 indicates the unit has just “powered on” or reset and is ready to receive host commands. This notification is primarily for the HOST to know the status of the MC-8.

  • Page 9: Mc-8 Parameter Notification By Id

    The MC-8 will transmit parameter change notifications if they are enabled using the commands described by the Set Parameter Notification by Id user action or system action the MC-8 will transmit the current value of the parameter that is changing. 14). Transmission of the display buffer is asynchronous to other...

  • Page 10: Acknowledgment Packets

    Menu Background On/Off See V2.00 Parameter ID List 6.2 Acknowledgment Packets Acknowledge and No Acknowledge packets are used to communicate transmission, packet and data validation status. Both the HOST and MC-8 can transmit and receive these packets. MC_PARAM_NOTIFICATION_BY_ID ParamId(LSB) ParamId(MSB)

  • Page 11: Acknowledge

    The MC-8 serial communication protocol has been designed to respond to the following commands as described below. Each command is transmitted to the MC-8 with the identified parameters. If the command is successfully received and processed by the MC-8, the unit will respond with the described response packet or action.

  • Page 12: Restore Defaults

    Application Data: 6.3.1.2 MC-8 Response The MC-8 will perform an internal reset. After reset, the MC-8 will go through a soft power-up initialization. This includes transmitting the “Wakeup Notification Packet”. A soft reset does not reinitialize the MC-8. Nonvolatile RAM is maintained.

  • Page 13: Set Custom Name

    By transmitting the Wakeup Notification, the Host indicates it has just “powered on” or reset and is ready to receive MC-8 Notifications or Responses. The Host is assumed to be asleep upon power up of the MC-8. Host status is maintained during standby.

  • Page 14: Host Sleep

    6.3.6.2 Data Description 6.3.7 Get Communication Configuration This command is a request to the MC-8 for the current communications configuration for the serial port and protocol. The MC-8 responds to this command with a Communication Configuration Packet. 6.3.7.1 Command Packet Description...

  • Page 15: Set Communication Configuration

    The data values transmitted will be copied over to the registers stored in nonvolatile RAM. The MC-8 will respond with an ACK Packet. 6.3.9 Set Mute The Set Mute Command message allows the RS232 users to set/clear the MC-8 mute state directly. 6.3.9.1 Command Packet Description Application Header:...

  • Page 16: Send Display String Command

    6.3.9.4 Data Validation The data value transmitted to the MC-8 will be verified as a valid value. If it is valid the MC-8 will set/clear the mute and respond with an ACK Packet. If the data value is invalid the MC-8 will respond with a DC_INVALID_DATA error NAK.

  • Page 17: Mc-8 Get Parameter Definition By Id

    6.3.11.2 Data Description ParamId: Data Type: Max Value: 6.3.11.3 Data Validation: If the ParamId is not a valid Id the MC-8 will respond with a NAK packet and error code DC_ INVALID_PARAM_ID. Null (0x00) terminated ASCII character string. 40 Characters. ParamId(LSB)
  • Page 18 Lexicon 6.3.11.4 Parameter Definition Response Packet The following Packet has been defined as follows for MC-8 V1.00. Future releases may modify this definition. Application Header: Command Data Count Application Data: Data[0] Data[1] Data[2] Data[3] Data[4] Data[5] Data[6] Data[7-27] Data[28]-Data[108] Data[108] 6.3.11.5 Data Description...
  • Page 19 Parameter Type. Parameter Path: This is a zero terminated ASCII character string describing the parameter's name and path in the units parameter tree structure. MC-8 Serial Communications Protocol ParamType Type Description Unsigned 8 bit integer(0 to...

  • Page 20: Mc-8 Set Parameter Value By Id

    Parameter is writeable 6.3.12 MC-8 Set Parameter Value by Id MC-8 Set Parameter by Id command sets the parameter value equal to the value sent in the command packet and then runs the appropriate functional changes associated with changing the given parameter.

  • Page 21: Mc-8 Set Parameter Value By Id, No Run

    The ParamId must be a valid Parameter. The ParamType must be valid for the given ParamId. If either of these conditions is not true, the MC-8 will respond with a NAK packet and error code DC _ INVALID_PARAM_ID. The data value size cannot exceed the size of a given data type. A value that does exceed the size of a give data type will be truncated to the appropriate size.
  • Page 22 Lexicon 6.3.14.2 MC-8 Unit Configuration Response Packet Application Header: Command Data Count Application Data: Data[0] Data[1] Data[2] Data[3] Data[4] Data[5] Data[6] Data[7] Data[8] Data[9] Data[10] Data[11] Data[12] Data[13] Data[14] Data[15] Data[16] Data[17] Data[18] Data[19] Data[20] Data[21] Data[22] Data[23] Data[24] Data[25]...
  • Page 23 Software Level: The following table shows the values assigned to the possible software levels: Note: SW level indicates the status of the MC-8 internal application software. Software Major Revision: An unsigned 8 bit integer value indicating the unit’s major software version.

  • Page 24: Mc-8 Send Ir Command

    The KeyCode is processed as a valid IR code. No acknowledgment will be sent from MC-8. 6.3.15.4 Data Validation The KeyCode data will be verified as a legal IR code. If the Code is not valid the MC-8 will not respond.

  • Page 25: Mc-8 Get Parameter Value By Id

    Lexicon 6.3.16 MC-8 Get Parameter Value by Id Request to MC-8 for the current value of a given parameter. The MC-8 will respond with a “Parameter Value Packet”. 6.3.16.1 Command Packet Description Application Header: Command Data Count Application Data: Data[0] Data[1] 6.3.16.2 Data Description...

  • Page 26: Mc-8 Parameter Get Value String By Id

    If a parameter has been enabled for notification the MC-8 will transmit its current value whenever it has been changed due to any user or system action. For the details of the MC-8 notification packet, see the Parameter Notification by Id description 6.3.18 MC-8 Parameter Get Value String by Id...

  • Page 27: Mc-8 Clear All Parameter Notifications

    Lexicon 6.3.18.3 Data Validation If ParamId exceeds the its maximum value, the MC-8 will ignore the command and transmit a DC_NAK command with an error code DC_INVALID_PARAM_ID. 6.3.18.4 MC-8 Value String Response Packet Application Header: Command Data Count Application Data: Data[0] - Data[20] 6.3.18.5 Data Description...
  • Page 28 Data[9] 6.3.20.3 Data Description System Volume: Data Type: Max: Min: Current Input: Data Type: Definition/Conversion: MC-8 Input Ids Current Effect Id: Data Type: Definition/Conversion: MC-8 Mode Ids Current Input Sample Rate: Data Type: MC-8 Serial Communications Protocol MC_RESP_SYS_STATUS System Volume...

  • Page 29: Mc-8 Get Zone Status

    Min: Video Sync: Data Type: TRUE: FALSE: 6.3.21 MC-8 Get Zone Status This command is a request to MC-8 for current Zone 2 Status. MC-8 will respond with “Zone2 Status Packet”. 6.3.21.1 Command Packet Description Application Header: Command Data Count...

  • Page 30: Mc-8 Set System Volume

    Zone 2 Balance: Data Type: Max: Min: 6.3.22 MC-8 Set System Volume This command is a request to the MC-8 to set the system volume with the value in this packet. 6.3.22.1 Command Packet Description Application Header: Command Data Count...

  • Page 31: Mc-8 Set Main Balance

    The MC-8 will assign the value from the packet to the system volume. 6.3.22.4 Data Validation If a value is passed that exceeds the maximum value of that parameter the MC-8 will ignore the command and transmit a DC_NAK command with an error code DC_INVALID_DATA.

  • Page 32: Mc-8 Set Active Effect By Id

    The MC-8 will assign the value from the packet to the front/back balance. 6.3.24.4 Data Validation If a value is passed that exceeds the maximum value of that parameter the MC-8 will ignore the command and transmit a NAK command with an error code DC_INVALID_DATA.

  • Page 33: Mc-8 Set Zone2 Left/Right Balance

    InputId: Data Type: Definition/Conversion: MC-8 Input Ids 6.3.28.3 Data Validation: The InputId must be a valid Input number. If it is not valid, the MC-8 will respond with a NAK packet and error code DC_INVALID_INPUT. MC-8 Serial Communications Protocol MC_CMD_SET_ZONE2_BALANCE...

  • Page 34: Mc-8 Set Input Name By Id

    MC-8 will copy the InputName to the given input. 6.3.29.4 Data Validation: The InputId must be a valid Input Id. If it is not the MC-8 will respond with a NAK packet and error code DC_INVALID_INPUT. If the InputName string exceeds the INPUT_NAME_LENGTH, the MC-8 will truncate the string to the INPUT_NAME_LENGTH.

  • Page 35: Appendix A Command Codes

    MC_CMD_SET_SYS_PARAM_VALUE_BY_ID MC_CMD_SET_SYS_PARAM_VALUE_BY_ID_NO_RUN MC_CMD_GET_CONFIG MC_CMD_IR MC_CMD_GET_PARAM_VALUE_BY_ID MC_CMD_SET_PARAM_NOTIFICATION_BY_ID MC_CMD_PARAM_GET_VALUE_STRING_BY_ID MC_CMD_CLEAR_ALL_PARAM_NOTIFICATIONS MC_CMD_GET_SYS_STATUS MC_GET_REC_ZONE2_STATUS MC_CMD_SET_SYS_VOLUME MC_CMD_SET_SYS_BALANCE DC_CMD_SET_FRONT_BACK_BALANCE MC_CMD_SET_EFFECT MC_CMD_SET_ZONE2_VOLUME MC_CMD_SET_ZONE2_BALANCE MC_CMD_GET_INPUT_NAME MC_CMD_SET_INPUT_NAME MC-8 Serial Communications Protocol 0x00 0x01 0x02 0x03 0x05 0x10 0x11 0x12 0x13 0x2B 0x2C 0x2F 0x30 0x31 0x33 0x35 0x36 0x37...

  • Page 36: Appendix B Error Codes

    Error NO_ACK DC_NO_ERROR DC_ERR_PARITY DC_ERR_FRAMING DC_ERR_OVERRUN DC_ERR_INVALID_PACKET DC_ERR_TIME_OUT DC_ERR_BUFFER_FULL DC_INVALID_COUNT DC_INVALID_CMD DC_INVALID_DATA DC_INVALID_ADDRESS DC_INVALID_EFFECT_ID DC_INVALID_PARAM_ID DC_INVALID_NAME DC_INVALID_INPUT DC_ERR_READ_ONLY MC-8 Serial Communications Protocol 0x89 0x8C 0x8F 0x91 0x92 0x93 0x94 0x95 0x96 0xE0 0xE1 Code(Hex) 0x00 0x01 0x02 0x03 0x04 0x05...

  • Page 37: Appendix C Mc-8 Ir Codes

    Lexicon Appendix C MC-8 IR Codes FUNCTION STANDBY BLUE LIGHT STAT UP_ARROW LEFT_ARROW_DONE Reserved RIGHT_ARROW_SELECT DN_ARROW MUTE MODE_INCR MODE_DECR VOL_INCR VOL_DECR MAIN_DVD_1 MAIN_DVD_2 MAIN_SAT MAIN_VCR MAIN_TV MAIN_CD MAIN_TUNER MAIN_AUX Reserved Reserved Reserved Reserved LOGIC7_LOGO DOLBY_LOGO DTS_LOGO THX_LOGO MUSIC TV_L_LOGO MAIN_TOGGLE_7_5...
  • Page 38 DIRECT_MONO_LOGIC_IR DIRECT_MONO_SURROUND_IR DIRECT_MONO_IR DIRECT_PROLOGIC_IR DIRECT_PROLOGIC2_IR DIRECT_PL2MUSIC_IR DIRECT_THX_CINEMA_IR DIRECT_DTS_NEO_FILM_IR DIRECT_DTS_NEO_MUSIC_IR DIRECT__51_LOGIC7_IR DIRECT__51_TV_LOGIC_IR DIRECT__51_MUSIC_IR DIRECT__51_THX_IR DIRECT_DOLBY_DIGITAL_IR DIRECT__51_2CHANNEL_IR DIRECT__51_MONO_LOGIC_IR DIRECT__51_MONO_SURROUND_IR DIRECT__51_MONO_IR MC-8 Serial Communications Protocol Code(hex) Mode 0xAC DIRECT_DTS_LOGIC7_IR 0xAD DIRECT_DTS_MUSIC_IR 0xAE DIRECT_DTS_2CHANNEL_IR 0xAF DIRECT_DTS_IR 0xB0 DIRECT_DTS_THX_IR 0xB1 DIRECT__51_AD_FILM_IR 0xB2 DIRECT__51_AD_MUSIC_IR 0xB3 DIRECT__51_AD_2CHANNEL_IR...

  • Page 39: Appendix D Mc-8 Input Ids

    Lexicon Appendix D MC-8 Input Ids Appendix E Protocol Constants Constant FPD_LINE_LENGTH PARAM_NAME_LENGTH CUSTOM_NAME_LENGTH INPUT_NAME_LENGTH PARAM_PATH_LENGTH INTER_PACKET_TIME MC-8 Serial Communications Protocol MC-8 MC-8 Input Name Input Id DVD1 DVD2 TUNER Value (Dec) 0xF1 0xF2 Units Chars Chars Chars Chars Chars...

  • Page 40: Appendix F Mc-8 Mode Ids

    Lexicon Appendix F MC-8 Mode Ids MC-8 Mode Name NONE Internal Noise L7 Film L7 TV L7 Music 2-Ch Surround 2-Channel Mono Logic Mono Surround Mono 5.1 L7 Film 5.1 L7 TV 5.1 L7 Music THX(ex) Dolby Digital 5.1 2-Channel 5.1 Mono Logic...

  • Page 41: Application Notes And Examples

    When the MC-8 is powered on it will initialize the serial port and then transmit the DC_WAKEUP Packet, and look for an ACK from the HOST. Currently, if an ACK is not received, the MC-8 continues to operate. This message is mostly for the HOST to know if the MC-8 is in an operational state.
  • Page 42 Lexicon If the command is received without error the MC-8 responds with the UNIT_CONFIG response packet: DLL DC CMD App DC DATA3 DATA4 DATA5 DATA6 DATA7 SW MJ SW MN PTCL MJ PTCL MN REV DATA10 DATA11 DATA12 DATA13 DATA14 DATA15 DATA16 DATA17...

  • Page 43: Send Mc-8 Ir Command Example

    Code “ ”(26 hex). To transmit other IR Key Codes the user would replace MAIN_CD this byte with other IR key codes as found in MC-8 IR Codes 37). Byte 5: End of Packet (F2 hex) MC-8 Serial Communications Protocol...

  • Page 44: Mc8 V2.00 Parameter Id List

    0x0011 PARAM.INPUTS.OFF.SVID_16_9 0x0012 PARAM.INPUTS.OFF.SVIDOSD_4_3 0x0013 PARAM.INPUTS.OFF.COMPNTOSD 0x0014 PARAM.INPUTS.OFF._51_AD_EFFECT 0x0015 PARAM.INPUTS.OFF.LIVEEFFCT 0x0016 PARAM.INPUTS.DVD1 0x0017 PARAM.INPUTS.DVD1.INPNAME 0x0018 PARAM.INPUTS.DVD1.DIGIN 0x0019 PARAM.INPUTS.DVD1.ANLGIN 0x001A PARAM.INPUTS.DVD1.ANLGTRIM 0x001B PARAM.INPUTS.DVD1.TRIMMODE 0x001C PARAM.INPUTS.DVD1.VIDEOIN 0x001D PARAM.INPUTS.DVD1.CH2EFFCT 0x001E PARAM.INPUTS.DVD1.DDEFFCT 0x001F PARAM.INPUTS.DVD1.DTSEFFCT 0x0020 PARAM.INPUTS.DVD1.MSRCMODE 0x0021 PARAM.INPUTS.DVD1.ZSRCMODE 0x0022 PARAM.INPUTS.DVD1.ANLGBYPASS MC-8 Serial Communications Protocol...
  • Page 45 0x003B PARAM.INPUTS.DVD2.COMPNTOSD 0x003C PARAM.INPUTS.DVD2._51_AD_EFFECT 0x003D PARAM.INPUTS.DVD2.LIVEEFFCT 0x003E PARAM.INPUTS.CD 0x003F PARAM.INPUTS.CD.INPNAME 0x0040 PARAM.INPUTS.CD.DIGIN 0x0041 PARAM.INPUTS.CD.ANLGIN 0x0042 PARAM.INPUTS.CD.ANLGTRIM 0x0043 PARAM.INPUTS.CD.TRIMMODE 0x0044 PARAM.INPUTS.CD.VIDEOIN 0x0045 PARAM.INPUTS.CD.CH2EFFCT 0x0046 PARAM.INPUTS.CD.DDEFFCT 0x0047 PARAM.INPUTS.CD.DTSEFFCT 0x0048 PARAM.INPUTS.CD.MSRCMODE 0x0049 PARAM.INPUTS.CD.ZSRCMODE 0x004A PARAM.INPUTS.CD.ANLGBYPASS 0x004B PARAM.INPUTS.CD.TRIGGER1 0x004C PARAM.INPUTS.CD.COMPONENTIN MC-8 Serial Communications Protocol...
  • Page 46 0x0065 PARAM.INPUTS.TUNER.LIVEEFFCT 0x0066 PARAM.INPUTS.TV 0x0067 PARAM.INPUTS.TV.INPNAME 0x0068 PARAM.INPUTS.TV.DIGIN 0x0069 PARAM.INPUTS.TV.ANLGIN 0x006A PARAM.INPUTS.TV.ANLGTRIM 0x006B PARAM.INPUTS.TV.TRIMMODE 0x006C PARAM.INPUTS.TV.VIDEOIN 0x006D PARAM.INPUTS.TV.CH2EFFCT 0x006E PARAM.INPUTS.TV.DDEFFCT 0x006F PARAM.INPUTS.TV.DTSEFFCT 0x0070 PARAM.INPUTS.TV.MSRCMODE 0x0071 PARAM.INPUTS.TV.ZSRCMODE 0x0072 PARAM.INPUTS.TV.ANLGBYPASS 0x0073 PARAM.INPUTS.TV.TRIGGER1 0x0074 PARAM.INPUTS.TV.COMPONENTIN 0x0075 PARAM.INPUTS.TV.SVID_16_9 0x0076 PARAM.INPUTS.TV.SVIDOSD_4_3 MC-8 Serial Communications Protocol...
  • Page 47 0x008F PARAM.INPUTS.SAT.INPNAME 0x0090 PARAM.INPUTS.SAT.DIGIN 0x0091 PARAM.INPUTS.SAT.ANLGIN 0x0092 PARAM.INPUTS.SAT.ANLGTRIM 0x0093 PARAM.INPUTS.SAT.TRIMMODE 0x0094 PARAM.INPUTS.SAT.VIDEOIN 0x0095 PARAM.INPUTS.SAT.CH2EFFCT 0x0096 PARAM.INPUTS.SAT.DDEFFCT 0x0097 PARAM.INPUTS.SAT.DTSEFFCT 0x0098 PARAM.INPUTS.SAT.MSRCMODE 0x0099 PARAM.INPUTS.SAT.ZSRCMODE 0x009A PARAM.INPUTS.SAT.ANLGBYPASS 0x009B PARAM.INPUTS.SAT.TRIGGER1 0x009C PARAM.INPUTS.SAT.COMPONENTIN 0x009D PARAM.INPUTS.SAT.SVID_16_9 0x009E PARAM.INPUTS.SAT.SVIDOSD_4_3 0x009F PARAM.INPUTS.SAT.COMPNTOSD 0x00A0 PARAM.INPUTS.SAT._51_AD_EFFECT MC-8 Serial Communications Protocol...
  • Page 48 0x00B9 PARAM.INPUTS.LEVELS.INRIGHT 0x00BA PARAM.INPUTS.LEVELS.INCENTER 0x00BB PARAM.INPUTS.LEVELS.INLFE 0x00BC PARAM.INPUTS.LEVELS.SIDELEFT 0x00BD PARAM.INPUTS.LEVELS.SIDERIGHT 0x00BE PARAM.INPUTS.LEVELS.REARLEFT 0x00BF PARAM.INPUTS.LEVELS.REARRIGHT 0x00C0 PARAM.INPUTS.LEVELS.PEAK 0x00C1 PARAM.INPUTS.AUTOTRIM 0x00C2 PARAM.MAIN 0x00C3 PARAM.MAIN.OUTPUTS 0x00C4 PARAM.MAIN.OUTPUTS.FRONT 0x00C5 PARAM.MAIN.OUTPUTS.FRONT.HP_XOVER 0x00C6 PARAM.MAIN.OUTPUTS.FRONT.LEFT 0x00C7 PARAM.MAIN.OUTPUTS.FRONT.LEFT.DISTANCE 0x00C8 PARAM.MAIN.OUTPUTS.FRONT.LEFT.OUTLEVEL 0x00C9 PARAM.MAIN.OUTPUTS.FRONT.RIGHT 0x00CA PARAM.MAIN.OUTPUTS.FRONT.RIGHT.DISTANCE MC-8 Serial Communications Protocol...
  • Page 49 0x00E3 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SUB_R_DIST 0x00E4 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SUB_R_LEVEL 0x00E5 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_LFE_DIST 0x00E6 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_LFE_LEVEL 0x00E7 PARAM.MAIN.OUTPUTS.CENTER 0x00E8 PARAM.MAIN.OUTPUTS.CENTER.HP_XOVER 0x00E9 PARAM.MAIN.OUTPUTS.CENTER.DISTANCE 0x00EA PARAM.MAIN.OUTPUTS.CENTER.OUTLEVEL 0x00EB PARAM.MAIN.OUTPUTS.CENTER.FULL_AND_SUB 0x00EC PARAM.MAIN.OUTPUTS.SIDE 0x00ED PARAM.MAIN.OUTPUTS.SIDE.HP_XOVER 0x00EE PARAM.MAIN.OUTPUTS.SIDE.LEFT 0x00EF PARAM.MAIN.OUTPUTS.SIDE.LEFT.DISTANCE 0x00F0 PARAM.MAIN.OUTPUTS.SIDE.LEFT.OUTLEVEL 0x00F1 PARAM.MAIN.OUTPUTS.SIDE.RIGHT 0x00F2 PARAM.MAIN.OUTPUTS.SIDE.RIGHT.DISTANCE 0x00F3 PARAM.MAIN.OUTPUTS.SIDE.RIGHT.OUTLEVEL 0x00F4 PARAM.MAIN.OUTPUTS.SIDE.FULL_AND_SUB MC-8 Serial Communications Protocol...
  • Page 50 0x010D PARAM.MAIN.OUTPUTS.THX_ASA 0x010E PARAM.MAIN.DATA_STREAM 0x010F PARAM.MAIN.DATA_STREAM.SAMPLE_RATE 0x0110 PARAM.MAIN.DATA_STREAM.DATA_TYPE 0x0111 PARAM.MAIN.DATA_STREAM.CHANNELS 0x0112 PARAM.MAIN.INPUT 0x0113 PARAM.MAIN.EFFECT 0x0114 PARAM.MAIN.VOLUME 0x0115 PARAM.MAIN.BALANCE 0x0116 PARAM.MAIN.FADER 0x0117 PARAM.MAIN.PWRONVOL 0x0118 PARAM.MAIN.MUTEBY 0x0119 PARAM.MAIN.BASS 0x011A PARAM.MAIN.TREBLE 0x011B PARAM.MAIN.TILT 0x011C PARAM.MAIN.MUTE 0x011D PARAM.MAIN.MODE 0x011E PARAM.MAIN.LOUDNESS MC-8 Serial Communications Protocol...
  • Page 51 0x0137 PARAM.ZONE.BALANCE 0x0138 PARAM.ZONE.PWRONVOL 0x0139 PARAM.ZONE.MUTE 0x013A PARAM.ZONE.TRIGGER1 0x013B PARAM.EFFECTS 0x013C PARAM.EFFECTS.INT_NOISE 0x013D PARAM.EFFECTS.INT_NOISE.NAME 0x013E PARAM.EFFECTS.INT_NOISE.OUTPUTLEVELS 0x013F PARAM.EFFECTS.INT_NOISE.OUTPUTLEVELS.CNTROUTLEVEL 0x0140 PARAM.EFFECTS.INT_NOISE.OUTPUTLEVELS.SIDEOUTLEVEL 0x0141 PARAM.EFFECTS.INT_NOISE.OUTPUTLEVELS.REAROUTLEVEL 0x0142 PARAM.EFFECTS.INT_NOISE.OUTPUTLEVELS.SUBOUTLEVEL 0x0143 PARAM.EFFECTS.INT_NOISE.TRIGGER1 0x0144 PARAM.EFFECTS.INT_NOISE.FRONTOUTLEVEL 0x0145 PARAM.EFFECTS.LOGIC7 0x0146 PARAM.EFFECTS.LOGIC7.NAME 0x0147 PARAM.EFFECTS.LOGIC7.OUTPUTLEVELS 0x0148 PARAM.EFFECTS.LOGIC7.OUTPUTLEVELS.CNTROUTLEVEL MC-8 Serial Communications Protocol...
  • Page 52 0x0161 PARAM.EFFECTS.TV_LOGIC.OUTPUTLEVELS.REAROUTLEVEL 0x0162 PARAM.EFFECTS.TV_LOGIC.OUTPUTLEVELS.SUBOUTLEVEL 0x0163 PARAM.EFFECTS.TV_LOGIC.AUTOAZIMUTH 0x0164 PARAM.EFFECTS.TV_LOGIC.VOCALENH 0x0165 PARAM.EFFECTS.TV_LOGIC.FRONTSTEER 0x0166 PARAM.EFFECTS.TV_LOGIC.REEQ 0x0167 PARAM.EFFECTS.TV_LOGIC.SOUNDSTAGE 0x0168 PARAM.EFFECTS.TV_LOGIC.FIVESPKRENH 0x0169 PARAM.EFFECTS.TV_LOGIC.BASSENH 0x016A PARAM.EFFECTS.TV_LOGIC.SURRROLLOFF 0x016B PARAM.EFFECTS.TV_LOGIC.REARDLYOFF 0x016C PARAM.EFFECTS.TV_LOGIC.CENTERONOFF 0x016D PARAM.EFFECTS.TV_LOGIC.SEVENCHANNEL 0x016E PARAM.EFFECTS.TV_LOGIC.MONODETECT_ON 0x016F PARAM.EFFECTS.TV_LOGIC.SURRONOFF 0x0170 PARAM.EFFECTS.TV_LOGIC.TRIGGER1 0x0171 PARAM.EFFECTS.TV_LOGIC.HIFRONT_REARROLLOFF 0x0172 PARAM.EFFECTS.TV_LOGIC.AUTOBALON MC-8 Serial Communications Protocol...
  • Page 53 0x018B PARAM.EFFECTS.THX_CINEMA.NAME 0x018C PARAM.EFFECTS.THX_CINEMA.OUTPUTLEVELS 0x018D PARAM.EFFECTS.THX_CINEMA.OUTPUTLEVELS.CNTROUTLEVEL 0x018E PARAM.EFFECTS.THX_CINEMA.OUTPUTLEVELS.SIDEOUTLEVEL 0x018F PARAM.EFFECTS.THX_CINEMA.OUTPUTLEVELS.REAROUTLEVEL 0x0190 PARAM.EFFECTS.THX_CINEMA.OUTPUTLEVELS.SUBOUTLEVEL 0x0191 PARAM.EFFECTS.THX_CINEMA.TWO_CH_MUX 0x0192 PARAM.EFFECTS.THX_CINEMA.TWOCHCNTRMIX 0x0193 PARAM.EFFECTS.THX_CINEMA.CENTERDELAY 0x0194 PARAM.EFFECTS.THX_CINEMA.MONOREARON 0x0195 PARAM.EFFECTS.THX_CINEMA.DECORRELATE 0x0196 PARAM.EFFECTS.THX_CINEMA.VOCALENH 0x0197 PARAM.EFFECTS.THX_CINEMA.REEQ 0x0198 PARAM.EFFECTS.THX_CINEMA.SURDLY10_25 0x0199 PARAM.EFFECTS.THX_CINEMA.TIMBRE 0x019A PARAM.EFFECTS.THX_CINEMA.THXMODEON 0x019B PARAM.EFFECTS.THX_CINEMA.TRIGGER1 0x019C PARAM.EFFECTS.THX_CINEMA.REARTIMBRE MC-8 Serial Communications Protocol...
  • Page 54 0x01B5 PARAM.EFFECTS.PROLOGIC2.TWO_CH_MUX 0x01B6 PARAM.EFFECTS.PROLOGIC2.TWOCHCNTRMIX 0x01B7 PARAM.EFFECTS.PROLOGIC2.CENTERDELAY 0x01B8 PARAM.EFFECTS.PROLOGIC2.MONOREARON 0x01B9 PARAM.EFFECTS.PROLOGIC2.DECORRELATE 0x01BA PARAM.EFFECTS.PROLOGIC2.VOCALENH 0x01BB PARAM.EFFECTS.PROLOGIC2.REEQ 0x01BC PARAM.EFFECTS.PROLOGIC2.TRIGGER1 0x01BD PARAM.EFFECTS.PL2MUSIC 0x01BE PARAM.EFFECTS.PL2MUSIC.NAME 0x01BF PARAM.EFFECTS.PL2MUSIC.OUTPUTLEVELS 0x01C0 PARAM.EFFECTS.PL2MUSIC.OUTPUTLEVELS.CNTROUTLEVEL 0x01C1 PARAM.EFFECTS.PL2MUSIC.OUTPUTLEVELS.SIDEOUTLEVEL 0x01C2 PARAM.EFFECTS.PL2MUSIC.OUTPUTLEVELS.REAROUTLEVEL 0x01C3 PARAM.EFFECTS.PL2MUSIC.OUTPUTLEVELS.SUBOUTLEVEL 0x01C4 PARAM.EFFECTS.PL2MUSIC.SIDEREAR10DELAY 0x01C5 PARAM.EFFECTS.PL2MUSIC.TWO_CH_MUX 0x01C6 PARAM.EFFECTS.PL2MUSIC.TWOCHCNTRMIX MC-8 Serial Communications Protocol...
  • Page 55 0x01DF PARAM.EFFECTS.STEREO.OUTPUTLEVELS.CNTROUTLEVEL 0x01E0 PARAM.EFFECTS.STEREO.OUTPUTLEVELS.SIDEOUTLEVEL 0x01E1 PARAM.EFFECTS.STEREO.OUTPUTLEVELS.REAROUTLEVEL 0x01E2 PARAM.EFFECTS.STEREO.OUTPUTLEVELS.SUBOUTLEVEL 0x01E3 PARAM.EFFECTS.STEREO.AUTOAZIMUTH 0x01E4 PARAM.EFFECTS.STEREO.VOCALENH 0x01E5 PARAM.EFFECTS.STEREO.REEQ 0x01E6 PARAM.EFFECTS.STEREO.MONOCNTR 0x01E7 PARAM.EFFECTS.STEREO.TRIGGER1 0x01E8 PARAM.EFFECTS.MONO_LOGIC 0x01E9 PARAM.EFFECTS.MONO_LOGIC.NAME 0x01EA PARAM.EFFECTS.MONO_LOGIC.MONOENH 0x01EB PARAM.EFFECTS.MONO_LOGIC.MAINLEVEL 0x01EC PARAM.EFFECTS.MONO_LOGIC.ACADEMY 0x01ED PARAM.EFFECTS.MONO_LOGIC.SURRROLLOFF 0x01EE PARAM.EFFECTS.MONO_LOGIC.EFFECTLEVEL 0x01EF PARAM.EFFECTS.MONO_LOGIC.OUTPUTLEVELS 0x01F0 PARAM.EFFECTS.MONO_LOGIC.OUTPUTLEVELS.CNTROUTLEVEL MC-8 Serial Communications Protocol...
  • Page 56 0x0209 PARAM.EFFECTS.MONO_SURROUND.USEREVERB 0x020A PARAM.EFFECTS.MONO_SURROUND.TRIGGER1 0x020B PARAM.EFFECTS._51_LOGIC7 0x020C PARAM.EFFECTS._51_LOGIC7.NAME 0x020D PARAM.EFFECTS._51_LOGIC7.OUTPUTLEVELS 0x020E PARAM.EFFECTS._51_LOGIC7.OUTPUTLEVELS.CNTROUTLEVEL 0x020F PARAM.EFFECTS._51_LOGIC7.OUTPUTLEVELS.SIDEOUTLEVEL 0x0210 PARAM.EFFECTS._51_LOGIC7.OUTPUTLEVELS.REAROUTLEVEL 0x0211 PARAM.EFFECTS._51_LOGIC7.OUTPUTLEVELS.SUBOUTLEVEL 0x0212 PARAM.EFFECTS._51_LOGIC7.VOCALENH 0x0213 PARAM.EFFECTS._51_LOGIC7.FIVESPKRENH 0x0214 PARAM.EFFECTS._51_LOGIC7.BASSENH 0x0215 PARAM.EFFECTS._51_LOGIC7.REEQ 0x0216 PARAM.EFFECTS._51_LOGIC7.REARDLYOFF 0x0217 PARAM.EFFECTS._51_LOGIC7.COMPRESSION 0x0218 PARAM.EFFECTS._51_LOGIC7.LFEMIX 0x0219 PARAM.EFFECTS._51_LOGIC7.SOUNDSTAGE51 0x021A PARAM.EFFECTS._51_LOGIC7.FRONTSTEER51 MC-8 Serial Communications Protocol...
  • Page 57 0x0233 PARAM.EFFECTS._51_MUSIC.SEVENCHANNEL 0x0234 PARAM.EFFECTS._51_MUSIC.TRIGGER1 0x0235 PARAM.EFFECTS._51_MUSIC.MONOREARON51 0x0236 PARAM.EFFECTS._51_MUSIC.SURRROLLOFF 0x0237 PARAM.EFFECTS._51_MUSIC.CENTERONOFF 0x0238 PARAM.EFFECTS._51_MUSIC.SURRONOFF 0x0239 PARAM.EFFECTS._51_TV_LOGIC 0x023A PARAM.EFFECTS._51_TV_LOGIC.NAME 0x023B PARAM.EFFECTS._51_TV_LOGIC.OUTPUTLEVELS 0x023C PARAM.EFFECTS._51_TV_LOGIC.OUTPUTLEVELS.CNTROUTLEVEL 0x023D PARAM.EFFECTS._51_TV_LOGIC.OUTPUTLEVELS.SIDEOUTLEVEL 0x023E PARAM.EFFECTS._51_TV_LOGIC.OUTPUTLEVELS.REAROUTLEVEL 0x023F PARAM.EFFECTS._51_TV_LOGIC.OUTPUTLEVELS.SUBOUTLEVEL 0x0240 PARAM.EFFECTS._51_TV_LOGIC.VOCALENH 0x0241 PARAM.EFFECTS._51_TV_LOGIC.FIVESPKRENH 0x0242 PARAM.EFFECTS._51_TV_LOGIC.BASSENH 0x0243 PARAM.EFFECTS._51_TV_LOGIC.REEQ 0x0244 PARAM.EFFECTS._51_TV_LOGIC.REARDLYOFF MC-8 Serial Communications Protocol...
  • Page 58 0x025D PARAM.EFFECTS._51_THX.DECORRELATE 0x025E PARAM.EFFECTS._51_THX.VOCALENH 0x025F PARAM.EFFECTS._51_THX.REEQ 0x0260 PARAM.EFFECTS._51_THX.TIMBRE 0x0261 PARAM.EFFECTS._51_THX.SURREX 0x0262 PARAM.EFFECTS._51_THX.THXMODEON 0x0263 PARAM.EFFECTS._51_THX.TRIGGER1 0x0264 PARAM.EFFECTS._51_THX.REARTIMBRE 0x0265 PARAM.EFFECTS.DOLBY_DIGITAL 0x0266 PARAM.EFFECTS.DOLBY_DIGITAL.NAME 0x0267 PARAM.EFFECTS.DOLBY_DIGITAL.OUTPUTLEVELS 0x0268 PARAM.EFFECTS.DOLBY_DIGITAL.OUTPUTLEVELS.CNTROUTLEVEL 0x0269 PARAM.EFFECTS.DOLBY_DIGITAL.OUTPUTLEVELS.SIDEOUTLEVEL 0x026A PARAM.EFFECTS.DOLBY_DIGITAL.OUTPUTLEVELS.REAROUTLEVEL 0x026B PARAM.EFFECTS.DOLBY_DIGITAL.OUTPUTLEVELS.SUBOUTLEVEL 0x026C PARAM.EFFECTS.DOLBY_DIGITAL.COMPRESSION 0x026D PARAM.EFFECTS.DOLBY_DIGITAL.LFEMIX 0x026E PARAM.EFFECTS.DOLBY_DIGITAL.TWO_CH_MUX MC-8 Serial Communications Protocol...
  • Page 59 0x0286 PARAM.EFFECTS._51_2CHANNEL.SURRMIX 0x0287 PARAM.EFFECTS._51_2CHANNEL.MASTERLEVEL 0x0288 PARAM.EFFECTS._51_2CHANNEL.TRIGGER1 0x0289 PARAM.EFFECTS._51_2CHANNEL.MONOREARON 0x028A PARAM.EFFECTS._51_MONO_SURROUND 0x028B PARAM.EFFECTS._51_MONO_SURROUND.NAME 0x028C PARAM.EFFECTS._51_MONO_SURROUND.OUTPUTLEVELS PARAM.EFFECTS._51_MONO_SURROUND.OUTPUTLEVELS.CNTROUTLEVE 0x028D 0x028E PARAM.EFFECTS._51_MONO_SURROUND.OUTPUTLEVELS.SIDEOUTLEVEL PARAM.EFFECTS._51_MONO_SURROUND.OUTPUTLEVELS.REAROUTLEVE 0x028F 0x0290 PARAM.EFFECTS._51_MONO_SURROUND.OUTPUTLEVELS.SUBOUTLEVEL 0x0291 PARAM.EFFECTS._51_MONO_SURROUND.USEREVERB 0x0292 PARAM.EFFECTS._51_MONO_SURROUND.TRIGGER1 0x0293 PARAM.EFFECTS._51_MONO_LOGIC 0x0294 PARAM.EFFECTS._51_MONO_LOGIC.NAME 0x0295 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS 0x0296 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS.CNTROUTLEVEL 0x0297 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS.SIDEOUTLEVEL MC-8 Serial Communications Protocol...
  • Page 60 0x02B0 PARAM.EFFECTS._51_MONO.NAME 0x02B1 PARAM.EFFECTS._51_MONO.OUTPUTLEVELS 0x02B2 PARAM.EFFECTS._51_MONO.OUTPUTLEVELS.CNTROUTLEVEL 0x02B3 PARAM.EFFECTS._51_MONO.OUTPUTLEVELS.SIDEOUTLEVEL 0x02B4 PARAM.EFFECTS._51_MONO.OUTPUTLEVELS.REAROUTLEVEL 0x02B5 PARAM.EFFECTS._51_MONO.OUTPUTLEVELS.SUBOUTLEVEL 0x02B6 PARAM.EFFECTS._51_MONO.USEREVERB 0x02B7 PARAM.EFFECTS._51_MONO.FRONTOUTLEVEL 0x02B8 PARAM.EFFECTS._51_MONO.TRIGGER1 0x02B9 PARAM.EFFECTS.DTS 0x02BA PARAM.EFFECTS.DTS.NAME 0x02BB PARAM.EFFECTS.DTS.OUTPUTLEVELS 0x02BC PARAM.EFFECTS.DTS.OUTPUTLEVELS.CNTROUTLEVEL 0x02BD PARAM.EFFECTS.DTS.OUTPUTLEVELS.SIDEOUTLEVEL 0x02BE PARAM.EFFECTS.DTS.OUTPUTLEVELS.REAROUTLEVEL 0x02BF PARAM.EFFECTS.DTS.OUTPUTLEVELS.SUBOUTLEVEL 0x02C0 PARAM.EFFECTS.DTS.LFEMIX 0x02C1 PARAM.EFFECTS.DTS.TWO_CH_MUX MC-8 Serial Communications Protocol...
  • Page 61 0x02DA PARAM.EFFECTS.DTS_LOGIC7.SEVENCHANNEL 0x02DB PARAM.EFFECTS.DTS_LOGIC7.TRIGGER1 0x02DC PARAM.EFFECTS.DTS_LOGIC7.MONOREARON51 0x02DD PARAM.EFFECTS.DTS_LOGIC7.DTS_ES_DETECT 0x02DE PARAM.EFFECTS.DTS_LOGIC7.SURRROLLOFF 0x02DF PARAM.EFFECTS.DTS_LOGIC7.CENTERONOFF 0x02E0 PARAM.EFFECTS.DTS_LOGIC7.SURRONOFF 0x02E1 PARAM.EFFECTS.DTS_THX 0x02E2 PARAM.EFFECTS.DTS_THX.NAME 0x02E3 PARAM.EFFECTS.DTS_THX.OUTPUTLEVELS 0x02E4 PARAM.EFFECTS.DTS_THX.OUTPUTLEVELS.CNTROUTLEVEL 0x02E5 PARAM.EFFECTS.DTS_THX.OUTPUTLEVELS.SIDEOUTLEVEL 0x02E6 PARAM.EFFECTS.DTS_THX.OUTPUTLEVELS.REAROUTLEVEL 0x02E7 PARAM.EFFECTS.DTS_THX.OUTPUTLEVELS.SUBOUTLEVEL 0x02E8 PARAM.EFFECTS.DTS_THX.LFEMIX 0x02E9 PARAM.EFFECTS.DTS_THX.TWO_CH_MUX 0x02EA PARAM.EFFECTS.DTS_THX.TWOCHCNTRMIX 0x02EB PARAM.EFFECTS.DTS_THX.CENTERDELAY MC-8 Serial Communications Protocol...
  • Page 62 0x0304 PARAM.EFFECTS.DTS_MUSIC.FRONTSTEER51 0x0305 PARAM.EFFECTS.DTS_MUSIC.SURREX 0x0306 PARAM.EFFECTS.DTS_MUSIC.SEVENCHANNEL 0x0307 PARAM.EFFECTS.DTS_MUSIC.TRIGGER1 0x0308 PARAM.EFFECTS.DTS_MUSIC.MONOREARON51 0x0309 PARAM.EFFECTS.DTS_MUSIC.DTS_ES_DETECT 0x030A PARAM.EFFECTS.DTS_MUSIC.SURRROLLOFF 0x030B PARAM.EFFECTS.DTS_MUSIC.CENTERONOFF 0x030C PARAM.EFFECTS.DTS_MUSIC.SURRONOFF 0x030D PARAM.EFFECTS.DTS_2CHANNEL 0x030E PARAM.EFFECTS.DTS_2CHANNEL.NAME 0x030F PARAM.EFFECTS.DTS_2CHANNEL.OUTPUTLEVELS 0x0310 PARAM.EFFECTS.DTS_2CHANNEL.OUTPUTLEVELS.CNTROUTLEVEL 0x0311 PARAM.EFFECTS.DTS_2CHANNEL.OUTPUTLEVELS.SIDEOUTLEVEL 0x0312 PARAM.EFFECTS.DTS_2CHANNEL.OUTPUTLEVELS.REAROUTLEVEL 0x0313 PARAM.EFFECTS.DTS_2CHANNEL.OUTPUTLEVELS.SUBOUTLEVEL 0x0314 PARAM.EFFECTS.DTS_2CHANNEL.LFEMIX_2CH 0x0315 PARAM.EFFECTS.DTS_2CHANNEL.TWO_CH_MUX MC-8 Serial Communications Protocol...
  • Page 63 0x032E PARAM.EFFECTS.DTS_NEO_FILM.OUTPUTLEVELS.SIDEOUTLEVEL 0x032F PARAM.EFFECTS.DTS_NEO_FILM.OUTPUTLEVELS.REAROUTLEVEL 0x0330 PARAM.EFFECTS.DTS_NEO_FILM.OUTPUTLEVELS.SUBOUTLEVEL 0x0331 PARAM.EFFECTS.DTS_NEO_FILM.TRIGGER1 0x0332 PARAM.EFFECTS.DTS_NEO_FILM.DECORRELATE 0x0333 PARAM.EFFECTS.DTS_NEO_FILM.MONOREARON 0x0334 PARAM.EFFECTS.DTS_NEO_THX 0x0335 PARAM.EFFECTS.DTS_NEO_THX.NAME 0x0336 PARAM.EFFECTS.DTS_NEO_THX.OUTPUTLEVELS 0x0337 PARAM.EFFECTS.DTS_NEO_THX.OUTPUTLEVELS.CNTROUTLEVEL 0x0338 PARAM.EFFECTS.DTS_NEO_THX.OUTPUTLEVELS.SIDEOUTLEVEL 0x0339 PARAM.EFFECTS.DTS_NEO_THX.OUTPUTLEVELS.REAROUTLEVEL 0x033A PARAM.EFFECTS.DTS_NEO_THX.OUTPUTLEVELS.SUBOUTLEVEL 0x033B PARAM.EFFECTS.DTS_NEO_THX.TRIGGER1 0x033C PARAM.EFFECTS.DTS_NEO_THX.DECORRELATE 0x033D PARAM.EFFECTS.DTS_NEO_THX.REEQ 0x033E PARAM.EFFECTS.DTS_NEO_THX.MONOREARON 0x033F PARAM.EFFECTS.DTS_NEO_THX.REARTIMBRE MC-8 Serial Communications Protocol...
  • Page 64 0x0358 PARAM.EFFECTS.DTS_THX_MUSIC.OUTPUTLEVELS 0x0359 PARAM.EFFECTS.DTS_THX_MUSIC.OUTPUTLEVELS.CNTROUTLEVEL 0x035A PARAM.EFFECTS.DTS_THX_MUSIC.OUTPUTLEVELS.SIDEOUTLEVEL 0x035B PARAM.EFFECTS.DTS_THX_MUSIC.OUTPUTLEVELS.REAROUTLEVEL 0x035C PARAM.EFFECTS.DTS_THX_MUSIC.OUTPUTLEVELS.SUBOUTLEVEL 0x035D PARAM.EFFECTS.DTS_THX_MUSIC.LFEMIX 0x035E PARAM.EFFECTS.DTS_THX_MUSIC.TWO_CH_MUX 0x035F PARAM.EFFECTS.DTS_THX_MUSIC.TWOCHCNTRMIX 0x0360 PARAM.EFFECTS.DTS_THX_MUSIC.CENTERDELAY 0x0361 PARAM.EFFECTS.DTS_THX_MUSIC.MONOREARON 0x0362 PARAM.EFFECTS.DTS_THX_MUSIC.DECORRELATE 0x0363 PARAM.EFFECTS.DTS_THX_MUSIC.VOCALENH 0x0364 PARAM.EFFECTS.DTS_THX_MUSIC.REEQ 0x0365 PARAM.EFFECTS.DTS_THX_MUSIC.TIMBRE 0x0366 PARAM.EFFECTS.DTS_THX_MUSIC.SURREX 0x0367 PARAM.EFFECTS.DTS_THX_MUSIC.THXMODEON 0x0368 PARAM.EFFECTS.DTS_THX_MUSIC.TRIGGER1 0x0369 PARAM.EFFECTS.DTS_THX_MUSIC.REARTIMBRE MC-8 Serial Communications Protocol...
  • Page 65 0x0382 PARAM.EFFECTS.CONCERT_HALL 0x0383 PARAM.EFFECTS.CONCERT_HALL.NAME 0x0384 PARAM.EFFECTS.CONCERT_HALL.OUTPUTLEVELS 0x0385 PARAM.EFFECTS.CONCERT_HALL.OUTPUTLEVELS.CNTROUTLEVEL 0x0386 PARAM.EFFECTS.CONCERT_HALL.OUTPUTLEVELS.SIDEOUTLEVEL 0x0387 PARAM.EFFECTS.CONCERT_HALL.OUTPUTLEVELS.REAROUTLEVEL 0x0388 PARAM.EFFECTS.CONCERT_HALL.OUTPUTLEVELS.SUBOUTLEVEL 0x0389 PARAM.EFFECTS.CONCERT_HALL.TRIGGER1 0x038A PARAM.EFFECTS.CONCERT_HALL.EFFECTLEVEL 0x038B PARAM.EFFECTS.CONCERT_HALL.SURRROLLOFF 0x038C PARAM.EFFECTS.CONCERT_HALL.SIZE 0x038D PARAM.EFFECTS.CONCERT_HALL.PREDELAY 0x038E PARAM.EFFECTS.CONCERT_HALL.MIDRT 0x038F PARAM.EFFECTS.CONCERT_HALL.SPEECHDETECT 0x0390 PARAM.EFFECTS.CONCERT_HALL.CENTERDRYLEVEL 0x0391 PARAM.EFFECTS.CHURCH 0x0392 PARAM.EFFECTS.CHURCH.NAME 0x0393 PARAM.EFFECTS.CHURCH.OUTPUTLEVELS MC-8 Serial Communications Protocol...
  • Page 66 0x03AC PARAM.EFFECTS.CATHEDRAL.SURRROLLOFF 0x03AD PARAM.EFFECTS.CATHEDRAL.SIZE2 0x03AE PARAM.EFFECTS.CATHEDRAL.PREDELAY 0x03AF PARAM.EFFECTS.CATHEDRAL.MIDRT 0x03B0 PARAM.EFFECTS.CATHEDRAL.SPEECHDETECT 0x03B1 PARAM.EFFECTS.CATHEDRAL.MONOLOGICFRONTEND 0x03B2 PARAM.EFFECTS.CATHEDRAL.STEREORVB 0x03B3 PARAM.EFFECTS.CATHEDRAL.BASSRT 0x03B4 PARAM.EFFECTS.CATHEDRAL.CENTERDRYLEVEL 0x03B5 PARAM.EFFECTS.MUSIC_SURR 0x03B6 PARAM.EFFECTS.MUSIC_SURR.NAME 0x03B7 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS 0x03B8 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.CNTROUTLEVEL 0x03B9 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.SIDEOUTLEVEL 0x03BA PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.REAROUTLEVEL 0x03BB PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.SUBOUTLEVEL 0x03BC PARAM.EFFECTS.MUSIC_SURR.AUTOAZIMUTH 0x03BD PARAM.EFFECTS.MUSIC_SURR.VOCALENH MC-8 Serial Communications Protocol...
  • Page 67 0x03D6 PARAM.EFFECTS.PANORAMA.BASSWIDTH 0x03D7 PARAM.EFFECTS.PANORAMA.TRIGGER1 0x03D8 PARAM.EFFECTS.PANORAMA.REARDLYOFF 0x03D9 PARAM.EFFECTS.PANORAMA.BASSCONTENT 0x03DA PARAM.EFFECTS.PANORAMA.SPEAKERANGLE 0x03DB PARAM.EFFECTS.PANORAMA.FINETIMEALIGN 0x03DC PARAM.EFFECTS.PANORAMA.CALSOURCE 0x03DD PARAM.EFFECTS.PANORAMA.CALIBRATEACTIVE 0x03DE PARAM.EFFECTS.PROLOGIC_THX 0x03DF PARAM.EFFECTS.PROLOGIC_THX.NAME 0x03E0 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS 0x03E1 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.CNTROUTLEVEL 0x03E2 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.SIDEOUTLEVEL 0x03E3 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.REAROUTLEVEL 0x03E4 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.SUBOUTLEVEL 0x03E5 PARAM.EFFECTS.PROLOGIC_THX.TWO_CH_MUX 0x03E6 PARAM.EFFECTS.PROLOGIC_THX.TWOCHCNTRMIX 0x03E7 PARAM.EFFECTS.PROLOGIC_THX.CENTERDELAY MC-8 Serial Communications Protocol...
  • Page 68 1030 0x0406 PARAM.EFFECTS.LIVE1.WANDER 1031 0x0407 PARAM.EFFECTS.LIVE1.RECIRC 1032 0x0408 PARAM.EFFECTS.LIVE1.SHAPE 1033 0x0409 PARAM.EFFECTS.LIVE1.LVGNRDNDB 1034 0x040A PARAM.EFFECTS.LIVE1.INPUTDB 1035 0x040B PARAM.EFFECTS.LIVE1.OUTPUTDB 1036 0x040C PARAM.EFFECTS.LIVE1.LVGNRDNOUTBIAS 1037 0x040D PARAM.EFFECTS.LIVE1.LVGNRDN 1038 0x040E PARAM.EFFECTS.LIVE1.MICAUTOBAL 1039 0x040F PARAM.EFFECTS.LIVE1.LVGNRDNTHRESH 1040 0x0410 PARAM.EFFECTS.LIVE1.INLIMTHRESH 1041 0x0411 PARAM.EFFECTS.LIVE2 MC-8 Serial Communications Protocol...
  • Page 69 1072 0x0430 PARAM.EFFECTS.LIVE2.LVGNRDNTHRESH 1073 0x0431 PARAM.EFFECTS.LIVE2.INLIMTHRESH 1074 0x0432 PARAM.EFFECTS.LIVE3 1075 0x0433 PARAM.EFFECTS.LIVE3.NAME 1076 0x0434 PARAM.EFFECTS.LIVE3.OUTPUTLEVELS 1077 0x0435 PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.CNTROUTLEVEL 1078 0x0436 PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.SIDEOUTLEVEL 1079 0x0437 PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.REAROUTLEVEL 1080 0x0438 PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.SUBOUTLEVEL 1081 0x0439 PARAM.EFFECTS.LIVE3.TRIGGER1 1082 0x043A PARAM.EFFECTS.LIVE3.EFFECTLEVEL 1083 0x043B PARAM.EFFECTS.LIVE3.SURRROLLOFF MC-8 Serial Communications Protocol...
  • Page 70 1114 0x045A PARAM.EFFECTS.LIVE_CAL.TRIGGER1 1115 0x045B PARAM.EFFECTS.PL2XMOVIE 1116 0x045C PARAM.EFFECTS.PL2XMOVIE.NAME 1117 0x045D PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS 1118 0x045E PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.CNTROUTLEVEL 1119 0x045F PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.SIDEOUTLEVEL 1120 0x0460 PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.REAROUTLEVEL 1121 0x0461 PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.SUBOUTLEVEL 1122 0x0462 PARAM.EFFECTS.PL2XMOVIE.SIDEREAR10DELAY 1123 0x0463 PARAM.EFFECTS.PL2XMOVIE.TWO_CH_MUX 1124 0x0464 PARAM.EFFECTS.PL2XMOVIE.TWOCHCNTRMIX 1125 0x0465 PARAM.EFFECTS.PL2XMOVIE.CENTERDELAY MC-8 Serial Communications Protocol...
  • Page 71 1156 0x0484 PARAM.EFFECTS.PL2XTHX.NAME 1157 0x0485 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS 1158 0x0486 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.CNTROUTLEVEL 1159 0x0487 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.SIDEOUTLEVEL 1160 0x0488 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.REAROUTLEVEL 1161 0x0489 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.SUBOUTLEVEL 1162 0x048A PARAM.EFFECTS.PL2XTHX.TWO_CH_MUX 1163 0x048B PARAM.EFFECTS.PL2XTHX.TWOCHCNTRMIX 1164 0x048C PARAM.EFFECTS.PL2XTHX.CENTERDELAY 1165 0x048D PARAM.EFFECTS.PL2XTHX.MONOREARON 1166 0x048E PARAM.EFFECTS.PL2XTHX.DECORRELATE 1167 0x048F PARAM.EFFECTS.PL2XTHX.VOCALENH MC-8 Serial Communications Protocol...
  • Page 72 1198 0x04AE PARAM.EFFECTS._51_PL2X_MUSIC.OUTPUTLEVELS.REAROUTLEVEL 1199 0x04AF PARAM.EFFECTS._51_PL2X_MUSIC.OUTPUTLEVELS.SUBOUTLEVEL 1200 0x04B0 PARAM.EFFECTS._51_PL2X_MUSIC.COMPRESSION 1201 0x04B1 PARAM.EFFECTS._51_PL2X_MUSIC.LFEMIX 1202 0x04B2 PARAM.EFFECTS._51_PL2X_MUSIC.TWO_CH_MUX 1203 0x04B3 PARAM.EFFECTS._51_PL2X_MUSIC.TWOCHCNTRMIX 1204 0x04B4 PARAM.EFFECTS._51_PL2X_MUSIC.CENTERDELAY 1205 0x04B5 PARAM.EFFECTS._51_PL2X_MUSIC.DECORRELATE 1206 0x04B6 PARAM.EFFECTS._51_PL2X_MUSIC.VOCALENH 1207 0x04B7 PARAM.EFFECTS._51_PL2X_MUSIC.REEQ 1208 0x04B8 PARAM.EFFECTS._51_PL2X_MUSIC.TRIGGER1 1209 0x04B9 PARAM.EFFECTS._51_PL2X_MUSIC.MONOREARON MC-8 Serial Communications Protocol...
  • Page 73 1240 0x04D8 PARAM.LANGUAGE 1241 0x04D9 PARAM.LIVEEQ 1242 0x04DA PARAM.LIVEEQ.LEFTFILTERS 1243 0x04DB PARAM.LIVEEQ.LEFTFILTERS.FILTER0 1244 0x04DC PARAM.LIVEEQ.LEFTFILTERS.FILTER0.Q 1245 0x04DD PARAM.LIVEEQ.LEFTFILTERS.FILTER0.FREQ 1246 0x04DE PARAM.LIVEEQ.LEFTFILTERS.FILTER0.GAIN 1247 0x04DF PARAM.LIVEEQ.LEFTFILTERS.FILTER0.FLTRTYPE 1248 0x04E0 PARAM.LIVEEQ.LEFTFILTERS.FILTER1 1249 0x04E1 PARAM.LIVEEQ.LEFTFILTERS.FILTER1.Q 1250 0x04E2 PARAM.LIVEEQ.LEFTFILTERS.FILTER1.FREQ 1251 0x04E3 PARAM.LIVEEQ.LEFTFILTERS.FILTER1.GAIN MC-8 Serial Communications Protocol...
  • Page 74 1282 0x0502 PARAM.LIVEEQ.RIGHTFILTERS.FILTER0.FREQ 1283 0x0503 PARAM.LIVEEQ.RIGHTFILTERS.FILTER0.GAIN 1284 0x0504 PARAM.LIVEEQ.RIGHTFILTERS.FILTER0.FLTRTYPE 1285 0x0505 PARAM.LIVEEQ.RIGHTFILTERS.FILTER1 1286 0x0506 PARAM.LIVEEQ.RIGHTFILTERS.FILTER1.Q 1287 0x0507 PARAM.LIVEEQ.RIGHTFILTERS.FILTER1.FREQ 1288 0x0508 PARAM.LIVEEQ.RIGHTFILTERS.FILTER1.GAIN 1289 0x0509 PARAM.LIVEEQ.RIGHTFILTERS.FILTER1.FLTRTYPE 1290 0x050A PARAM.LIVEEQ.RIGHTFILTERS.FILTER2 1291 0x050B PARAM.LIVEEQ.RIGHTFILTERS.FILTER2.Q 1292 0x050C PARAM.LIVEEQ.RIGHTFILTERS.FILTER2.FREQ 1293 0x050D PARAM.LIVEEQ.RIGHTFILTERS.FILTER2.GAIN MC-8 Serial Communications Protocol...
  • Page 75 1313 0x0521 PARAM.LIVEEQ.RIGHTFILTERS.FILTER6.GAIN 1314 0x0522 PARAM.LIVEEQ.RIGHTFILTERS.FILTER6.FLTRTYPE 1315 0x0523 PARAM.LIVEEQ.RIGHTFILTERS.FILTERSET 1316 0x0524 PARAM.LIVEEQ.MAXVOLUME 1317 0x0525 PARAM.LIVEEQ.MICTRIM 1318 0x0526 PARAM.LIVEEQ.LIVESOURCE 1319 0x0527 PARAM.LIVEEQ.LIVEEQENABLED 1320 0x0528 PARAM.LIVEEQ.PREVIOUSVOLUME 1321 0x0529 PARAM.LIVEEQ.PREVIOUSBASS 1322 0x052A PARAM.LIVEEQ.PREVIOUSTREBLE 1323 0x052B PARAM.LIVEEQ.PREVIOUSTILT 1324 0x052C PARAM.LIVEEQ.PREVIOUSLOUDNESS MC-8 Serial Communications Protocol...
  • Page 76 Lexicon Part No. 070-15332 | Rev 1 | 10/05 Lexicon, Inc. Tel 781-280-0300 3 Oak Park Fax 781-280-0490 Bedford, MA 01730-1413 www.lexicon.com Customer Service Tel 781-280-0300 Fax 781-280-0495 (Sales) Fax 781-280-0499 (Service)
