Dts 2-Channel - Lexicon DC-1 - ADDENDUM Owner's Manual Addendum

DC-1 Digital Controller
This Effect mixes DTS Digital 5.1 information for two-channel playback.
These soundtracks can be recorded onto two-channel formats, or played
back through left and right front speakers. The mix is designed to play back
with full surround when decoded through Logic 7. In mixing a film with
very heavy use of the Low Frequency Effects Channel, it may be desirable
to lower LFE MIX LEVEL.
Parameter
SURROUND MIX
LFE MIX LEVEL
SUBWOOFER LVL
CUSTOM
SURROUND MIX allows independent adjustment of the level of the sur-
round channels. Many multichannel-encoded soundtracks sound better
when down-mixed to two channels with the surround level increased by
approximately 2-3dB.
LFE MIX LEVEL allows separate level attenuation of the LFE channel,
which is ultimately mixed to the subwoofer output. As the bass from as
many as five other channels is added to the LFE, it can significantly raise
subwoofer output levels — and create the risk of damage to a system.
Careful adjustment of this parameter will allow you to achieve proper tonal
balance and reduce the risk of damage.
SUBWOOFER LVL boosts or cuts the subwoofer output level. Although the
normal subwoofer level is set during the calibration procedure, with some
recordings it may be desirable to increase or decrease this deep bass level.
Initial Value
+2dB
+0.0dB
+0dB
Range
-5 to +5dB
-10dB to 0dB
-5 to +5dB
DC-1Effects

DTS 2-Channel

DTS 2-Channel Parameters
41
