Pro Logic - Lexicon DC-1 - ADDENDUM Owner's Manual Addendum

DC-1 Effects
Music Surround Parameters

Pro Logic

Pro Logic Parameters
14
SUBWOOFER LVL boosts or cuts the subwoofer output level. Although the
normal subwoofer level is set during the calibration procedure, with some
Cont'd.
recordings it may be desirable to increase or decrease this deep bass level.
EFFECT LEVEL adjusts the loudness of the center, side and rear speakers.
When there are no side or rear speakers, it adjusts the amount of ambient
signal mixed into the main loudspeakers.
This Effect provides Dolby Pro Logic Surround decoding designed for any
Dolby Surround encoded movies, music, or television programs. The Pro
Logic effect is an industry standard. Lexicon's proprietary auto azimuth
correction makes it an improvement over other versions. (Even more
dramatic improvement has been implemented in more recent effects, such
as Logic 7 or TV Matrix.)
Parameter
AUTO AZIMUTH
DIALOG ENHANCE
SUBWOOFER LVL
EFFECT LEVEL
CUSTOM
AUTO AZIMUTH is short for auto azimuth error correction/automatic
input balance. Auto Azimuth should be set to ON for films, and OFF for
music. When ON, special patented algorithms continually monitor the
input signal and adjust both the relative level and time offset of the two
channels to keep the dialog properly centered and special effects properly
localized. This automatic feature is the reason the unit does not need an
input balance control for Dolby Surround decoding.
DIALOG ENHANCE boosts dialog in the center channel. By targeting
specific frequencies, it boosts dialog without raising the entire center
channel level (which would alter the output balance achieved during
calibration).
SUBWOOFER LVL boosts or cuts the subwoofer output level. Although the
normal subwoofer level is set during the calibration procedure, with some
recordings it may be desirable to increase or decrease this deep bass level.
EFFECT LEVEL adjusts the loudness of all speakers except the center and
subwoofer channels. This can be extremely useful in compensating for
soundtracks in which the dialog level is too low (decrease EFFECT LEVEL)
or when you want to make the surround presentation more spectacular
(increase EFFECT LEVEL).
Initial Value
ON
0.0dB 0.0dB, +3.0dB, +6.0dB
+0dB
+00dB
Lexicon
Range
ON/OFF
-5 to +5dB
-30 to +05dB
