INSTALLATION GUIDE
INDUSTRIAL ELECTRIC AXIAL FANS
OV 1 200
OV1 250
OV1 315
OVK1 200
OVK1 250
OVK1 315
INSTALLATION
Pencil
(Ø 10 mm for ОВ1/ОВК1 150,200,250)
Vents-US
400 Murray Road, Cincinnati, OH 45217, USA
Tel: 1-888-640-0925, 513-583-5786, Fax: 513-268-4597
E-mail: support@ventsus.com
www.vents-us.com
Drill
(Ø 12mm for ОВ1/ОВК1 315)
Tools required
Screwdriver
(NTS 10/60 for ОВ1/ОВК1 150,200,250)
(NTS 12/60 for ОВ1/ОВК1 315)
Dowel
for ОВ1/ОВК1 150,200,250)
(8,0x60 mm for ОВ1/ОВК1 315)
Screws
(6,0x60 mm
MIU_21EN-01
Advertisement
Related Manuals for Vents-us OV 1 200
Summary of Contents for Vents-us OV 1 200
- Page 1 INSTALLATION GUIDE INDUSTRIAL ELECTRIC AXIAL FANS OV 1 200 OV1 250 OV1 315 OVK1 200 OVK1 250 OVK1 315 INSTALLATION Tools required Pencil Drill Screwdriver Dowel Screws (Ø 10 mm for ОВ1/ОВК1 150,200,250) (NTS 10/60 for ОВ1/ОВК1 150,200,250) (6,0x60 mm for ОВ1/ОВК1 150,200,250)
- Page 2 4) Fix the fan. Connect the cables according to the wiring diagram. Install the terminal block cover. The fan must be connected using durable, insulated and heat-resistant cables and wires. The external lead-in must be equipped with a QF automatic circuit breaker Vents-US 400 Murray Road, Cincinnati, OH 45217, USA...
- Page 3 3) Remove the cable clamp. 4) Connect the cables according, install the cable clamp. 5) Install the terminal block cover Connection of the fan and standard wall socket Vents-US 400 Murray Road, Cincinnati, OH 45217, USA Tel: 1-888-640-0925, 513-583-5786, Fax: 513-268-4597 MIU_21EN-01 E-mail: support@ventsus.com...
- Page 4 HOUSE JUNCTION BOX GREEN GROUND AUT OMATIC SCREW SWITCH 120vAC, 60Hz HOUSE POWER ST ANDARD WALL SOCKET EAR TH GROUND Vents-US 400 Murray Road, Cincinnati, OH 45217, USA Tel: 1-888-640-0925, 513-583-5786, Fax: 513-268-4597 MIU_21EN-01 E-mail: support@ventsus.com www.vents-us.com...
