Guardian Fall Protection G1902 Manual

G1902
F Safety Station with Eyewash, Stainless Steel Bowl
Application:
Combination eyewash and shower safety station.
Eyewash features a stainless steel bowl with two GS-Plus™
spray-type outlet heads that deliver a flood of water for rinsing
eyes.
Shower Head:
10" diameter orange ABS plastic with 20 GPM
flow control.
Shower Valve:
1" IPS chrome plated brass stay-open ball valve.
Valve is US-made with chrome plated brass ball and PTFE seals.
Furnished with stainless steel actuating arm and 29" stainless
steel pull rod.
Spray Head Assembly:
Two GS-Plus™ spray heads. Each head
has a "flip top" dust cover, internal flow control and filter to
remove impurities from water flow.
Eyewash Bowl:
11-1/8" diameter stainless steel.
Eyewash Valve:
1/2" IPS chrome plated brass stay-open
ball valve. Valve is US-made with chrome plated brass ball and
PTFE seals.
Pipe and Fittings:
Schedule 40 galvanized steel. Furnished
with orange polyethylene pipe covers for high visibility and
corrosion resistance.
Supply:
1-1/4" NPT female top or side inlet.
Waste:
1-1/4" NPT female outlet. Outlet can be positioned at
either 9-1/4" or 19-5/8" above finished floor by reversing lower
pipe nipples.
Sign:
ANSI-compliant identification sign.
Quality Assurance:
Valve and spray head assemblies are
factory assembled and water tested prior to shipment.
Available Options
F GC
Powder coated finish on galvanized pipe and fittings.
Available colors include orange, yellow, red and green.
F GRN
Green ABS plastic shower head.
F YEL
Yellow ABS plastic shower head.
F SSH
Stainless steel shower head.
F AP275-200
Electric flashing light and alarm horn unit for
mounting on wall or vertical pipe. Light illuminates and horn
sounds when eyewash or shower is activated. Furnished
complete with flow switch and mounting hardware.
F AP250-015
Modesty curtain for mounting on safety station.
F G3800LF
Thermostatic mixing valve precisely blends hot
and cold water to deliver warm (tepid) water as required by
ANSI Z358.1-2014. Refer to "Tempering Valves" section for
complete technical and product selection information.
Guardian Equipment 312 447 8100
1140 N North Branch St 312 447 8101
Chicago, IL 60642 gesafety.com
TELEPHONE
FACSIMILE
Safety Stations with Eyewash
Listed 8116. Units have been
tested to and comply with
ANSI Z358.1-2014 and the
Uniform Plumbing Code.
