Ensure windows are kept clean to avoid scratching. DO NOT wash windows with brush. Wash
NOTICE
with clean, watered-down cloth or sponge and mild detergent. DO NOT clean windows while
dry. Use caution while cleaning in low temperatures as windows become more susceptible to
scratching and cracking. DO NOT roll up windows in low temperatures as this causes windows
to stiffen and crack. Windows should be clean when rolled up.
1. Bowless Top
2. Side Window - Left
- Rugged Ridge Summer Top Header (13308.05)
- Tailgate Bar
- Tailgate Retainer, RH
- Tailgate Retainer, LH
- Door Surround, Front RH
Montana Bowless Top, 4 Door JK
Supplied Components
(1)
3. Side Window - Right
(1)
4. Whisper Bar
Required Components
- Door Surround, Front LH
(55395757AC)
- Door Surround, Rear RH
(55395760AB)
- Door Surround, Rear LH
(55395761AB)
- Mounting Knob, Long
(5182824AF)
- Mounting Knob, Short
Page 1/9
(1)
(4)
(5182825AF)
(5182820AC)
(5182821AC)
(55397130AC)
(55397132AB)
Advertisement
Related Manuals for REALTRUCK Montana
Summary of Contents for REALTRUCK Montana
- Page 1 Page 1/9 Montana Bowless Top, 4 Door JK Ensure windows are kept clean to avoid scratching. DO NOT wash windows with brush. Wash NOTICE with clean, watered-down cloth or sponge and mild detergent. DO NOT clean windows while dry. Use caution while cleaning in low temperatures as windows become more susceptible to scratching and cracking.
- Page 2 Page 2/9 Montana Bowless Top, 4 Door JK 1. SOFT TOP VEHICLE: Refer to owner’s manual for instructions on lowering factory top. Once open, unscrew shoulder bolts fastening top to sport bar. HARD TOP VEHICLE: Refer to owner’s manual for instruction on removing factory hard top.
- Page 3 Page 3/9 Montana Bowless Top, 4 Door JK 4. Attach bowless top to header by looping top over header channel and fastening with snaps on underside of header. Image shown using Rugged Ridge NOTICE Windshield Header (13508.05 / 06) 5. Slide bowless top to front of vehicle, placing it over sport bar.
- Page 4 Page 4/9 Montana Bowless Top, 4 Door JK 8. Hook side plastic retainer over front door surround and hook into groove over front door. Repeat in “X” pattern for front and rear door surrounds (front left, back right, front right, back left).
- Page 5 Page 5/9 Montana Bowless Top, 4 Door JK 12. Pull two rear straps around rear sport bar and through plastic buckle. Tighten both sides. 13. Loop rear side strap around rear sport bar, moving toward outside of vehicle. 14. Loop strap under seatbelt stud, then back around to outside of vehicle.
- Page 6 Page 6/9 Montana Bowless Top, 4 Door JK 16. Install whisper bar by first inserting from front of vehicle over center sport bar. 17. Hook front end of whisper bar into pocket at front of vehicle. 18. Hook back end of whisper bar into rear pocket of bowless top.
- Page 7 Page 7/9 Montana Bowless Top, 4 Door JK 20. Zip top side window zipper. 21. Pull bottom plastic retainer of side window into side groove of body tub. Repeat step 19 - 21 for opposite side. 22. Zip rear window to top and side windows in rear...
- Page 8 Page 8/9 Montana Bowless Top, 4 Door JK 23. Loop top corner strap through plastic holder at rear corner of vehicle. Tighten strap and repeat for opposite side. 24. Fasten all Velcro around side and rear windows. 25. Insert remaining side window plastic retainers into...
- Page 9 Page 9/9 Montana Bowless Top, 4 Door JK 26. Slide tailgate bar into bottom of rear window and attach to receiver on tailgate. 27. Install metal hook on end of rear straps into body tub through cutout in rear panel and tighten. Repeat for opposite side.
