INSTALLATION INSTRUCTIONS
WARNING: DO NOT EXCEED PRODUCT RATING OR TOW VEHICLE LAMP LOAD RATING, WHICHEVER IS LOWER
APPLICATIONS
Make
Model
Honda
Odyssey
CUSTOM WIRING
CONNECTOR
WIRING LOCATION GUIDE
SUVS, MINI & FULL-SIZED VANS ( S )
Representative vehicle shown below
S3 - Behind driver side rear access panel
S3
NOTICE
All steps must be followed to ensure the wiring connector will
function properly. Once installed, test for proper function by
using a test light or connecting a properly wired trailer.
TOOLS NEEDED
Flat blade screwdriver
Panel trim removal tool
WARNING
The battery connection must be fuse-protected, 10-amp max.
Exceeding the product rating can cause loss of warranty,
overheating and potential fire. Do not exceed product rating
or tow vehicle lamp load rating, whichever is lower.
Signal Circuits - 3.0 amps per side
Tail / Running Circuits - 6.0 amps total
Check vehicle owner's manual or contact
the vehicle manufacturer for more information.
PAGE 1 • 56378-INS-RA
Advertisement
Related Manuals for curt 56378
Summary of Contents for curt 56378
- Page 1 Signal Circuits - 3.0 amps per side Tail / Running Circuits - 6.0 amps total Check vehicle owner's manual or contact the vehicle manufacturer for more information. PAGE 1 • 56378-INS-RA...
- Page 2 Reinstall all items removed during install. Install the (G). Insert the provided 10 amp fuse into the in-line fuse holder. provided 4-flat dust cover to help prevent corrosion. 56378-INS-RA • PAGE 2...
