Proxicast ANT-129-001 Manual

ANT-129-001
4G/5G Cross-Polarized (MIMO) 7-10 dBi Panel Antenna
Applications
• High Gain Directional Signal Enhancement
•
4G/LTE & 5G Modems, Routers & Hotspots
•
Poor Signal Coverage Areas
•
Indoor or Outdoor Use
•
Home / Office / Commercial Installations
Product Features
• Cross-Polarized MIMO Elements for Improved
Signal Quality & Performance
• Wide Beamwidth for Easy Positioning
• Weatherproof, Compact & Light-weight
• N Female Connectors
• Pole or Wall Mountable
• Compatible with all 4G & 5G Sub-6 Networks
• Compatible with most 4G & 5G Modems/Routers
General Description
Proxicast's dual polarized directional LTE MIMO antenna is ideal for signal enhancement in virtually any cellular
application.
It is compatible with all 4G/LTE and 5G Sub-6 data services from Verizon, AT&T, T-Mobile, Bell Mobility,
Rogers, Telus and most other cellular operators worldwide.
The antenna incorporates two separately fed ultra wideband high efficiency elements in a single housing which
focus radio energy into a 75 degree beam enabling connection to distant cell towers. The elements are set at 90
degree angles to provide cross-polarized multiple input / multiple output (MIMO) connectivity for LTE & 5G radio
equipment resulting in higher performance.
With appropriate adapter cables (not included), this antenna is compatible with cellular modems, hotspots and
routers from Cisco, Cradlepoint, Digi, Pepwave, Proxicast, Sierra Wireless and others.
The antenna's compact, light-weight rugged housing, heavy duty mounting hardware and corrosion-resistant
materials make it ideal for outdoor applications including building rooftops, utility poles, or surveillance trailers.
Data Sheet: Rev E 01/26/22
© Copyright Proxicast, LLC. All rights reserved.
Ordering Information
Part No.
ANT-129-001
- 1 of 11 - Disclaimer: Subject to change without notice
www.proxicast.com
Description
Proxicast 4G/5G Cross-
Polarized (MIMO) 7-10 dBi
Fixed-Mount Panel Antenna
• 1-877-777-7694
